Agilent Varian DS 402 - REBUILT

Call for Price

In stock
Weight 77 lbs
Pumping Speed 17.4 m3/h
Ultimate Pressure 2 x 10-3 mbar

Agilent Varian DS 402 Rotary Vane Vacuum Pump - REBUILT

The Agilent Varian two stage, direct drive, rotary vane mechanical pump incorporates hardened steel rotors, positively lubricated and frictionless hydrodynamic bearings, and stainless steel vane springs and filters. The spring loaded vanes do not rely on centrifugal force for sealing. An anti suckback valve with its integral rubber seal prevents oil from migrating back into the vacuum system should the motor be stopped inadvertently.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!


Free air displacement 50 Hz: 342 l/min (20.5 m3/h) 60 Hz: 410 l/min (14.5 cfm)
Pumping speed 50 Hz: 17.4 m3/h 60 Hz: 12.3 cfm
Ultimate partial pressure 10-4 mbar
Ultimate total pressure 2 x 10-3 mbar
Ultimate total pressure w/ gas ballast 2 x 10-2 mbar
Water vapor tolerance 30 mbar
Water vapor capacity 350 g/h
Oil capacity, min/max 0.5 / 1 l
Motor rating 1-phase 50 Hz: 0.75 kW 60 Hz: 0.90 kW
Nominal rotational speed 50 Hz: 1,500 rpm 60 Hz: 1,800 rpm
Weight (kg/lbs) 35/77
Inlet 25KF DN
Outlet 25KF DN


Type Label Description Download
Varian DS Series - REBUILT Instruction Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Agilent Varian DS 402 Rotary Vane Vacuum Pump - REBUILT

9499330 / 949-9330  DS 402  single-phase, universal 110-220V
9499331 / 949-9331  DS 402  three-phase, universal 230-460V
9499330M007 / 949-9330M007  DS 402 rough pump, for ICP-MS
