Agilent DS 602 - NEW

Starting at $5,701
In stock
Only %1 left
SKU
NEW_DS602
Weight 77 lbs
Motor Power 1 hp
Pumping Speed 14.7 cfm
Ultimate Pressure 2 x 10-3 torr

Agilent Varian DS 602 Rotary Vane Vacuum Pump - NEW

Thanks to a very simple and highly reliable design, these field-proven rotary vane pumps provide excellent vacuum performance. Agilent’s quality and manufacturing standards ensure that the DS Rotary Vane Pumps provide high pumping stability for light gases, low noise, minimal oil backstreaming, and a long operating life. The pump’s two-stage design allows for low operating temperature, minimal backstreaming at low pressure and good pumping efficiency and gas ballast in the low 10-2 mbar region. DS Rotary Vane Pumps conform to European Union directives (CE) and Restriction of Hazardous Substances (RoHS) requirements, and all pumps are UL and Canadian Standards Authority (CSA) approved

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Free air displacement 50 Hz: 504 l/min (30.2 m3/h) 60 Hz: 605 l/min (21.4 cfm)
Pumping speed 50 Hz: 25 m3/h 60 Hz: 17.6 cfm
Ultimate partial pressure 10-4 mbar
Ultimate total pressure 2 x 10-3 mbar
Ultimate total pressure w/ gas ballast 2 x 10-2 mbar
Water vapor tolerance 30 mbar
Water vapor capacity 550 g/h
Oil capacity, min/max 0.5 / 1 l
Motor rating 1-phase 50 Hz: 0.75 kW 60 Hz: 0.90 kW
Nominal rotational speed 50 Hz: 1,500 rpm 60 Hz: 1,800 rpm
Weight (kg/lbs) 35/77
Inlet 25KF DN
Outlet 25KF DN

Specifications

Type Label Description Download
Agilent DS Series - NEW User Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Agilent Varian DS 602 Rotary Vane Vacuum Pump - NEW

9499335        / 949-9335  DS 602  single-phase
9499336        / 949-9336  DS 602  three-phase
9499335M001 / 949-9335M001  DS 602  for mass spectrometers
9499365 / 949-9365  HS-652 Smart Pump
