Agilent TPS-mini - NEW
Call for Price
| Weight | 80 lbs |
|---|---|
| Pumping Speed | 48 l/s |
| Ultimate Pressure | < 2 x 10-7 mbar |
Agilent TPS-Mini Turbomolecular Vacuum Pumping System - NEW
The TPS-mini portable vacuum solution combines the TwisTorr 74 FS turbo pump and a dry 10 L/min diaphragm pump in a competive package. The lightest and smallest footprint in its category, it can be mounted in any position, either on a benchtop or directly on your system by its inlet flange. The onboard display can read system pressure from a variety of active gauges.
The TPS-mini is a ready-to-use dry-pumping system and ideal vacuum solution for small volume chambers and gauge calibration systems. The simple to use, on/off switch gives you high vacuum with the flip of a switch.
- Plug-and-pump design for easy, one-switch operation
- The smallest dimensions and lightest weight for easy portability and integration in any position
- Onboard electronics and display to read full range gauge pressure from atm to base pressure
- Embedded 70 l/s turbopump for operation down to 1 x 10-8 mbar
- Ready for Vacuum Link app to give full control of the turbo pump and pressure through your mobile phone
- Analog I/O provides accurate control of the system and pressure-driven setpoint
- Serial RS232 communication protocol with A-plus software enables turbo pump operation, control, and recording of system parameters (i.e., pressure)
- Wide voltage range (90–240 V) for worldwide operation
- CE/CSA certification
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| KF 40 | ISO 63 | CFF 4.5 in. | ||
| Pumping Speed (l/s) (w/ inlet screen) | N2 | 37 | 48 | |
| He | 29 | 44 | ||
| H2 | 23 | 32 | ||
| Base pressure* | 2 x 10-7 mbar | 5 x 10-8 mbar | ||
| Bakeout temperature | 80°C at inlet | 120°C at inlet | ||
| Pumpdown time (1 liter volume) | 60 sec. to 17 mbar; 114 sec. to 1 x 10-4 mbar; 140 sec. to 5 x 10-5 mbar | |||
| Turbo pump rotational speed | 70,000 RPM | |||
| Start-up time | 122 sec. | |||
| Operating position | Vertical, Horizontal, Upside down position | |||
| Operating ambient temperature | 5 to 35°C / 32 to 122°F | |||
| Input Voltage and Frequency | 90V to 240V AC; 50 Hz / 60 Hz | |||
| Maximum input power | 220 VA | |||
| Serial communications | RS-232 cable, 9-pin D-type male, 9-pin D-type female, A-Plus Software | |||
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Agilent TPS-mini Turbomolecular Vacuum Pump System - NEW G8703A#020 TPS-mini KF 40 G8703A#021 TPS-mini ISO 63 G8703A#022 TPS-mini CFF 4.5 in.
