CTI-Cryogenics Cryo-Torr 500 - REBUILT
| Weight |
205 lbs |
| Pumping Speed |
10,000 l/s |
Brooks CTI-Cryogenics Cryo-Torr 500 Vacuum Cryopump - REBUILT
Semiconductor Chamber Solutions at Edwards Vacuum (Part of the Atlas Copco Group) was Brooks.
The Brooks CTI-Cryogenics Cryo-Torr 500 rebuilt cryopump comes with a one year warranty. Contact us for compressors too. We also offer repair service.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Rough pump connection |
NW 25 ISO KF |
| Integrated hardware |
2nd stage diode |
Pumping speeds:
Water
Air
H2
Ar |
30,000 liters/sec
10,000 liters/sec
10,000 liters/sec
8,400 liters/sec |
| Ar throughput |
500 sccm (6 Torr-liters/sec) |
Capacity:
Ar
H2 |
3,000 std. liters
16 std. liters @ 5 x 10-6 Torr |
| Crossover |
500 Torr-liters |
Cooldown time
60 Hz
50 Hz |
180 minutes
220 minutes |
| Weight |
205 lbs. (93 kg) |
Specifications
| Type |
Label |
Description |
Download |
|
|
Brooks CTI-Cryogenics Cryo-Torr Series - REBUILT |
Installation, Operation & Maintenance Manual |
Download
|
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Brooks CTI-Cryogenics Cryo-Torr 500 Vacuum Cryopump - REBUILT
