Edwards E2M1.5 - NEW
| Weight | 22 lbs |
|---|---|
| Motor Power | 0.21 hp |
| Pumping Speed | 1.6 m3/h |
| Ultimate Pressure | 2.3 x 10-3 Torr |
Edwards E2M1.5 Two Stage Rotary Vane Vacuum Pump - NEW
E2M0.7 and E2M1.5 two stage oil sealed rotary vane pumps are renowned for achieving high ultimate vacuum and rapid pumping speeds, with quiet operation and compact size. Providing long term reliability, these pumps have become the industry standard in range of scientific and laboratory applications, and the ideal partner for your tubomolecular pump.
The drive is provided through and Oldham coupling by a single phase motor. The motor is totally enclosed and cooled by the motor-cooling fan which directs the air along the motor fins. A thermal overload devise is fitted to the motor which switches off the pump if the motor gets too hot, this will automatically reset when the motor cools down and restarts the pump.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Displacement (swept volume) | |
| 50 Hz | 1.8 m3h-1 / 1 ft3min-1 |
| 60 Hz | 2.2 m3h-1 / 1.3 ft3min-1 |
| Speed (Pneurop 6602) | |
| 50 Hz | 1.6 m3h-1 / 0.8 ft3min-1 |
| 60 Hz | 2.0 m3h-1 / 1.2 ft3min-1 |
| Ultimate vacuum (total pressure) | |
| w/out gas ballast | 3.0 x 10-3 mbar / 2.3 x 10-3 Torr |
| w/ full gas ballast | 2.5 x 10-2 mbar / 1.9 x 10-2 Torr |
| Inlet connection | NW10 flange |
| Outlet connection | Nozzle 11 mm external diameter removable from 3/8" BSP tapped hole |
| Maximum permitted pressure at outlet | 0.5 bar gauge / 7 psig |
| Maximum inlet pressure for water vapour | 15 mbar / 11 Torr |
| Maximum water vapour pumping rate | 16 gh-1 |
| Motor power | 0.16 kW |
| Nominal rotational speed 50/60Hz | 2,800/3,400 rpm |
| Power connector | IEC EN60320 C13 |
| Operating temperature range | 12 - 40°C |
| Weight, w/out oil | 10 kg / 22 lbs |
| Noise | 54 dB(A) @ 50 Hz |
| Noise w/ acoustic enclosure | 47 dB(A) @ 50 Hz |
| Oil capacity - maximum | 0.28 litre |
| Oil capacity - minimum | 0.2 litre |
| Recommended oil | Ultragrade 15 |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards E2M0.7, E2M1 & E2M1.5 - REBUILT | Instruction Manual | Download |
|
Edwards E2M0.7, E2M1 & E2M1.5 | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards MODEL E2M1.5 Two Stage Rotary Vane Vacuum Pump - NEW CODE NO. A371-32-919 / A37132919 E2M1.5 200-230V single-phase 50/60Hz IEC 60320 connectors CODE NO. A371-04-919 / A37104919 E2M1.5 interstage 200-230V 1-phase 50/60Hz IEC 60320 connectors CODE NO. A371-04-902 / A37104902 E2M1.5 interstage 100-120V 1-phase 50/60Hz IEC 60320 connectors Atlas Copco GVD 1.5 1-phase 110-120V 50/60Hz Atlas Copco GVD 1.5 1-phase 220-240V 50/60Hz
