Edwards GV80 DRYSTAR - REBUILT
Call for Price
| Weight | 364 lbs |
|---|---|
| Pumping Speed | 47 cfm |
| Ultimate Pressure | < 3 x 10-2 mbar |
Edwards GV80 DRYSTAR Industrial Dry Vacuum Pump - REBUILT
The DRYSTAR® GV80 – 600M range is based on the well proven Edwards reverse claw mechanism reaching a peak speed of 560 m3h-1 / 330 ft3min-1. The reverse claw mechanism results in short gas paths within the operating mechanism, providing the ability to handle large amounts of dust and water vapor, when compared to oil sealed pumps, without deterioration of performance. The GV range is able to handle large amounts of dust and water vapor with little or no effect on performance. Advantages to this include:
- Low cost of ownership in harsh conditions
- High reliability – dry mechanism proven in 100,000 installations
- Oil free mechanism – reduced maintenance
- Higher dust and water vapor tolerance
- Accessories to optimize pump performance to process variables
- Fast pump down with Edwards hydrokinetic drive booster pumps.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Peak pumping speed 50 Hz - m³/hr (cfm) | 80 (47) |
| Peak pumping speed 60 Hz - m³/hr (cfm) | 94 (56) |
| Ultimate pressure - mbar (Torr) | <3 x 10-2 (<2 x 10-2) |
| Full load power @ ultimate pressure - Kw (hp) | 3.6 (4.8) |
| Full load power @ peak pumping load - Kw (hp) | 5.8 (7.8) |
| Motor Rating | 4 kW / 5.4 hp |
| Cooling-water flow at 20°C | 8 l/min /2.1 gal/min |
| Seal purge (dry air) | < 25 l min-1 @ 0.4 bar / < 0.75 ft-1 @ 0.4 bar / < 0.75 ft3 min-1 @ 6 psig |
| Noise level | 78 dB(A) |
| Inlet connection | ISO40 |
| Outlet connection | NW40 |
| Weight | 165 / 364 lbs |
| Gear box oil capacity | 0.4 / 0.1 gal |
| Electrical supply | 240V / 380V / 400V / 415V |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards GV80 DRYSTAR - REBUILT | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards GV80 DRYSTAR Industrial Dry Vacuum Pump - REBUILT A70212916 / A702-12-916 GV80 380/415V 50Hz A70212995 / A702-12-995 GV80 230/460V 60Hz A70212934 / A702-12-934 GV80 200V 50Hz, 200-208/380V 60Hz A70215916 / A702-15-916 GV80 200V 50Hz, 200-208/380V 60Hz PFPE A70215995 / A702-15-995 GV80 230/460V 60Hz PFPE A70215934 / A702-15-934 GV80 200V 50Hz, 200-208/380V 60Hz PFPE NR8030000 / NR80-30-000 GV80 380/415V 50Hz NR8031000 / NR80-31-000 GV80 230/460V 60Hz NRA308000 / NRA3-08-000 GV80 PFPE 60Hz NRA719000 / NRA7-19-000 GV80 w/ IDC SSP silencer
