Edwards nES300 - NEW
Call for Price
In stock
SKU
NEW_nES300
| Weight | 539 lbs |
|---|---|
| Motor Power | 7.4 hp |
| Pumping Speed | 240 m3/h |
| Ultimate Pressure | 8 x 10-2 mbar |
Edwards nES300 Single Stage Rotary Vane Vacuum Pump - NEW
The Edwards nES single stage series represents the next advancement in oil sealed rotary vane vacuum pumps for use in a wide of range industries and applications. Offering high reliability, low life cycle cost and proven performance, the nES series provides an ideal solution to suit a broad range of requirements.
| Maximum Displacement | |
| 50 Hz | 280 m3h-1 /165 cfm |
| 60 Hz | 340 m3h-1 /200 cfm |
| Pumping Speed | |
| 50 Hz | 240 m3h-1 /141 cfm |
| 60 Hz | 290 m3h-1 /171 cfm |
| Ultimate vacuum (total pressure) no gas ballast | 0.08 mbar /0.06 Torr |
| Ultimate vacuum (total pressure) with gas ballast | 0.7 mbar /0.5 Torr |
| Inlet Connection | 63 ISO-F / G2 |
| Outlet Connection | 63 ISO-F / G2 |
| Max permitted outlet pressure | 1.15 bar gauge |
| Max water vapour pumping rate | |
| 50Hz | 1.3 kgh-1 /1.4 lbh-1 |
| 60Hz | 1.8 kgh-1 /1.9 lbh-1 |
| Weight | 244 kg /539 lb |
| Motor Protection rating | IP55 |
| Motor Power | |
| 50Hz | 5.5 kW /7.5 hp |
| 60Hz | 6.6 kW /10 hp |
| Noise level | |
| 50Hz | 72 dB(A) |
| 60Hz | 76 dB(A) |
| Oil refill capacity | 8.5-11.5 Litre |
| Recommended oil | Ultragrade 70 |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards nES Series - New | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards nES300 Single Stage Rotary Vane Vacuum Pump - NEW
