Edwards nES630 - NEW

Call for Price

In stock
SKU
NEW_nES630
Weight 1678 lbs
Motor Power 25 hp
Pumping Speed 640 m3/h
Ultimate Pressure 8 x 10-2 mbar

Edwards nES630 Single Stage Rotary Vane Vacuum Pump - NEW

The Edwards nES single stage series represents the next advancement in oil sealed rotary vane vacuum pumps for use in a wide of range industries and applications. Offering high reliability, low life cycle cost and proven performance, the nES series provides an ideal solution to suit a broad range of requirements.

Maximum Displacement
50 Hz 700 m3h-1 /412 cfm
60 Hz 840 m3h-1 /494 cfm
Pumping Speed
50 Hz 640 m3h-1 /377 cfm
60 Hz 755 m3h-1 /444 cfm
Ultimate vacuum (total pressure) no gas ballast 0.08 mbar /0.06 Torr
Ultimate vacuum (total pressure) with gas ballast 0.7 mbar /0.5 Torr
Inlet Connection 100 ISO-F / G3
Outlet Connection 100 ISO-F / G3
Max permitted outlet pressure 1.15 bar gauge
Max water vapour pumping rate
50Hz 17 kgh-1 /18 lbh-1
60Hz 24 kgh-1 /25 lbh-1
Weight 760 kg /1678 lb
Motor Protection rating IP55
Motor Power
50Hz 18.5 kW /25 hp
60Hz 21 kW / 30 hp
Noise level
50Hz 72 dB(A)
60Hz 75 dB(A)
Oil refill capacity 20-23 Litre
Recommended oil Ultragrade 70
Type Label Description Download
Edwards nES Series - New Instruction Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
