Edwards STP-iXR2206 - NEW
Call for Price
| Weight | 107 lbs |
|---|---|
| Pumping Speed | 1,850 l/s |
| Ultimate Pressure | 1 x 10-9 Torr |
Edwards STP-iXR2206 Turbomolecular Vacuum Pump - NEW
STP-iXR2206 series magnetically levitated turbo-molecular pump provides industry-leading performance and incorporates latest technology small power supply into the on-board control which is the same concept with STP-iXA2206/iXA3306 series. The pumping performance is improved by the newest developed revolutionary rotor design. This fully integrated product offers easy installation and small footprint as an all-in-one solution for all application tools.
- Eliminates connection cable between pump and control unit.
- Eliminates installation space and cost required by conventional rack type control unit.
- Compact design results in easy installation and small foot print.
- Highest pumping speed in the 8” TMP class, along with the STP-A1603.
- 32% reduced power consumption in the high gas flow area.
- I/O Remote, RS232C, RS485, STP-Link are standard ports.
- Profibus and DeviceNet can be selected as options.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet flange | ISO-200F |
| Backing port size | KF-40 |
| Pumping speed | |
| N2 | 1,850 l/s |
| H2 | 1,250 l/s |
| Ar | 1,650 l/s |
| Compression ratio | |
| N2 | > 108 |
| H2 | 1 x 103 |
| Ultimate pressure | 10-7 Pa (10-9 Torr) |
| Max working pressure | |
| Max. allowable backing pressure | 266 Pa (2 Torr) |
| Rated speed | 36,500 rpm |
| Run up time to 90% rated speed | |
| Starting time | ≤ 10 min |
| Mounting position | Any |
| Cooling method | Water |
| Water cooling temperature | 5 - 25°C |
| Pressure | 0.3 MPa |
| Lubricating oil | Not necessary |
| Ambient temperature range | 0 - 40°C |
| Storage temperature range | -5 - 55°C |
| Input voltage | 200 to 240 VAC |
| Max input power | 750 VA |
| Weight | 48 kg |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards STP-iXR2206 Turbomolecular Vacuum Pump - NEW
P/N YT85-0Z-000 / YT850Z000 STP-iXR2206 ISO-250F
P/N YT85-0Z-010 / YT850Z010 STP-iXR2206 VG-250
P/N YT85-0Z-020 / YT850Z020 STP-iXR2206 DN 250 CF
YT85-0Z-030 / YT850Z030 STP-iXR2206 ISO-250F Profibus -
