Kinney KT 150C - NEW

Starting at $18,284
In stock
Only %1 left
SKU
NEW_KT150C
Weight 800 lbs
Motor Power 7.5 hp
Pumping Speed 150 cfm
Ultimate Pressure 1.0 x 10-2 Torr

Kinney KT 150C Rotary Piston Vacuum Pump - NEW

The KT-Series pump has an oil circulating pump to provide adequate lubrication at all pressures including atmosphere. The vacuum pump has three cams and pistons pumping in parallel, driven by a common shaft. The cams are positioned on the shaft so as to dynamically balance moving parts to eliminate vibration. We also offer repair service backed by a one year warranty. Mist filters are sold separately.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Nominal displacement 150 cfm
Motor hp 7.5 hp
Total oil capacity 6 gal
Cooling water @ 60°F 1 gpm
Weight 800 lbs
Max gas ballast flow 11 cfm
Typical blank-off pressure with 5% GB     2.0 Torr
Ultimate pressure 1.0 × 10-2 Torr
Noise level 71 dBA

Specifications

Type Label Description Download
Kinney KT Series - NEW OPERATOR’S MANUAL Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Kinney KT 150C Rotary Piston Vacuum Pump - NEW
KT-150C 150 cfm / 255 m3/h
KT150C-M4A0 TEFC 3/60/230-460 KT150C-M4E0 TEFC 3/60/575 KT150C-M4D0 TEFC 3/50/220-380-440 KT150C-M7H0 Class 1 Div 1 Group C & D 3/60/230-460 KT150C-M7M0 Class 1 Div 1 Group C & D 3/60/575 KT150C-S000 KT150C STD Construction BARESHAFT
KT-300D 300 cfm / 510 m3/h
KT-500D 500 cfm / 850 m3/h
KT-850D 778 cfm / 1,322 m3/h
