Leybold SOGEVAC SV630 F - REBUILT
Weight
1411 lbs
Motor Power
20 hp
Pumping Speed
640 m3 /h
Ultimate Pressure
≤ 8 x 10-2 mbar
Leybold SOGEVAC SV630 Rotary Vane Vacuum Pump - REBUILT
The standard version of the SOGEVAC rotary vane pump series is suitable for rough industrial applications which can be customized to fit individual customer needs. A wide range of monitoring accessories and options are available. Different motor versions, inlet or exhaust ports, food-grade oil, food-grade paint, larger gas ballast are some examples of possible customizing.
Questions? send an email to our sales team!
SOGEVAC
SV630
SV630F
50 Hz
60 Hz
50 Hz
60 Hz
Nominal speed m3 h-1 (cfm)
700 (412.3)
840 (494.8)
700 (412.3)
840 (494.8)
Pumping speed m3 h-1 (cfm)
640 (377)
755 (444.7)
640 (377)
755 (444.7)
Ultimate partial pressure w/out gas ballast mbar (Torr)
< 8 x 10-2 (< 6 x 10-2 )
Ultimate total pressure w/ standard gas ballast mbar (Torr)
≤ 0.7 (≤ 0.53)
Gas ballast number / type
1 (+1 option) / manual
1 (+1 option) / EM 24 VDC
Water vapor tolerance w/ 1 gas ballast mbar (Torr)
40 (30)
50 (37.5)
25 (18.8)
30 (22.5)
Water vapor tolerance w/ 2 gas ballasts mbar (Torr)
60 (45)
70 (52.5)
35 (26.3)
40 (30)
Water vapor capacity w/ 1 gas ballast kg x h-1 (qt/hr)
17 (18)
24 (25)
11 (12)
14 (15)
Water vapor capacity w/ 2 gas ballasts kg x h-1 (qt/hr)
26 (27)
34 (35)
15 (16)
19 (20)
Oil capacity min. l (qt)
35 (37)
Noise level dB(A)
≤ 75
≤ 78
≤ 75
≤ 78
Admissable ambient temperature °C (°F)
12 to 40 (54 to 104)
Motor power kW (hp)
15 (20)
18.5 (25)
15 (20)
18.5 (25)
Nominal motor speed / pump speed min-1 (rpm)
1,500 / 990
1,800 / 1,170
1,500 / 990
1,800 / 1
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SOGEVAC SV630 Rotary Vane Vacuum Pump - REBUILT
95662 SV630 Air Cooled 200 V 50/60 Hz
95663 SV630 Air Cooled 460 V 60 Hz
9566391 SV630 220/380V,60Hz
95665 / 9566549 SV630 Air Cooled 230/460V 60Hz, 400V 50Hz
956659900002 SV630 USA Torlon vanes, a
956659900003 SOGEVAC SV630 USA PFPE PREP.(O
95666 SV630F Water cooled 200 V 50/60 Hz
95667 SV630F Water cooled 460 V 60 Hz
9566723 SV630F Euro, OEM-variant
9566727 SOGEVAC SV630F EURO OEM
9566735 SV630F Euro, OEM-variant
9566736 SOGEVAC SV630F EURO OEM
95669 SV630F Water cooled 230/460 V 60 Hz
9566907 SV630F USA and Roots adap
9566918 SV630F terminal in mot.ju
956690000003 SV630F USA/NEMA water coo
956699900001 SV630F USA/NEMA water coo
956699900002 SOGEVAC SV630F USA - TORLON VA
956699900003 SOGEVAC SV630F NEMA 50HZ-WATER
9566723 SV630F Euro, OEM-variant
