Leybold TURBOVAC MAG W 2000 / C / CT - REBUILT
Out of stock
Only %1 left
Weight
150.00 lbs
Pumping Speed
1750 l/s
Ultimate Pressure
1 x 10-8 mbar
Leybold Vacuum TURBOVAC MAG W 2000 / C / CT Turbomolecular Pump - REBUILT
Accuracy, precision and reliability those are the features of these magnetically-levitated turbomolecular pumps. High pumping speed and gas throughput for faster pump down time improve equipment cycle times. With its fully integrated converter and power supply, conventional rack-mounted controller and interconnecting cables are no longer necessary.
Questions? send an email to our sales team!
Pumping speed for N2 measured with splinter guard (PNEUROP)
1,650 l/s
Compression for N2
3.8 x 108
Compression for H2
9.6 x 103
Ultimate pressure as to DIN 28 400
2 x 10-10 mbar
Max. forevacuum pressure with nitrogen
1.0 mbar
Recommended forevacuum pressure
< 10-2 mbar
Rotor speed
28,800 min-1
Run-up time
< 8 min
Braking time with/without venting
1 / < 7.5 min
Cooling
water
Cooling connection, hose nipples for hose ID
8 to 10 mm
Cooling water temperature
15 to 30°C / 59 to 86°F
Weight
approx. 72 kg
High-vacuum connection flange
DN 250 CF
Forevacuum connection flange
DN 40 KF
Recommended backing pump
DRYVAC 50
Admissible ambient temperature
5 to 40°C / 40 to 104°F
Storage temperature
-10 to +60°C / 14 to 140°F
Max. relative air humidity
95% (non-condensing)
Degree of protection (EN 60529)
IP 20
Specifications
Type
Label
Description
Download
Leybold MAG W 1600 & 2000 - REBUILT
Operating Instructions
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC MAG 2000 / C / CT Turbomolecular Pump - REBUILT
89416 / 894 16 TURBOVAC MAG 2000 C DN 250 ISO
89417 / 894 17 TURBOVAC MAG W 2000 C DN 250 ISO-F
89430 / 894 30 TURBOVAC MAG 2000 CT DN 250 ISO-F
89431 / 894 31 TURBOVAC MAG W 2000 CT DN 250 ISO-F
400045V0008 TURBOVAC MAG 2000 C DN 250 CF
400045V0009 TURBOVAC MAG 2000 C DN 250 ISO
400045V0010 TURBOVAC MAG 2000 CTS DN 250 ISO-F 40K
400045V0011 TURBOVAC MAG 2000 CT DN 250 ISO-F 40KF
400045V0012 TURBOVAC MAG 2000 C DN 250 ISO-K 40KF
400045V0013 TURBOVAC MAG 2000 CT DN 250 ISO-K
400047V0001 TURBOVAC MAG W 2000 C Digital DN 250 ISO-F
400047V0002 TURBOVAC MAG W 2000 CT Digital
400047V0010 TURBOVAC MAG 2000 CTS DN 250 ISO-K
400047V0011 TURBOVAC MAG 2000 C DN 250 ISO-K
400047V0012 TURBOVAC MAG 2000 CT DN 250 ISO-K
