Leybold TURBOVAC MAG W 300 iP - REBUILT
Weight
26.5 lbs
Pumping Speed
300 l/s
Ultimate Pressure
1 x 10-8 mbar
Leybold Vacuum TURBOVAC MAG W 300 iP / iPL Turbomolecular Pump - REBUILT
Accuracy, precision and reliability those are the features of these magnetically-levitated turbomolecular pumps. High pumping speed and gas throughput for faster pump down time improve equipment cycle times. With its fully integrated converter and power supply, conventional rack-mounted controller and interconnecting cables are no longer necessary.
Questions? send an email to our sales team!
TURBOVAC
MAG W 300 iP
MAG W 400 iP
Inlet flange
DN 100 ISO-K
DN 100 CF
DN 160 ISO-K
DN 160 CF
Pumping speed
N2
300 l/s
365 l/s
Ar
260 l/s
330 l/s
He
260 l/s
280 l/s
H2
190 l/s
200 l/s
Operating speed
58,800 min-1 / 58,800 rpm
Compression ratio
N2
1.0 x 1010
H2
3.2 x 103
He
9.2 x 104
Ultimate pressure mbar / Torr
< 10-8 / < 0.75 x 10-8
< 10-10 / < 10-10
< 10-8 / < 0.75 x 10-8
< 10-10 / < 10-10
Max. degassing temperature
-
80°C (176°F)
-
80°C (176°F)
Max. foreline pressure for N2
8 mbar / 6 Torr
Recommended backing pump
TRIVAC D 2.5E / TRIVAC D 8 B
Run up time
< 5 min
Foreline flange
DN 16 ISO-KF - clamped
Purge / vent port
Water cooling connection
G 1/8" inside thread
Weight
12 kg / 26 lbs
Power supply
48 V
Ripple
< 2%
Max. power consumption
400 W
Power consumption at ultimate pressure
259 W
Max. DC current consumption
7.5 to 9.3 A
DC power supply voltage range
43 to 53 V
Max. contact rating for the relays
32 V / 0.5 A
Permissible ambient temperature during operation
+10 to +40°C (+50 to +104°F)
Permissible ambient temperature during storage
0 to +60°C (0 to +140°F)
Relative humidity of the air, non-condensing
5 to 85%
Protection class
IP 30
Overvoltage category
II
Pollution category
2
Specifications
Type
Label
Description
Download
Leybold MAG W 300 - 700 iP - REBUILT
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC MAG W 300 iP / iPL Turbomolecular Pump - REBUILT
410300V0705 MAG W 300 iPL DN 100 ISO-K
