Leybold TURBOVAC MAG W 400 iP - REBUILT
$9,700
In stock
Only %1 left
SKU
REBUILT_MAGW400IP
| Weight | 26.5 lbs |
|---|---|
| Pumping Speed | 365 l/s |
| Ultimate Pressure | 1 x 10-8 mbar |
Leybold Vacuum TURBOVAC MAG W 400 iP Turbomolecular Pump - REBUILT
Accuracy, precision and reliability those are the features of these magnetically-levitated turbomolecular pumps. High pumping speed and gas throughput for faster pump down time improve equipment cycle times. With its fully integrated converter and power supply, conventional rack-mounted controller and interconnecting cables are no longer necessary.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| TURBOVAC | MAG W 300 iP | MAG W 400 iP | ||
|---|---|---|---|---|
| Inlet flange | DN 100 ISO-K | DN 100 CF | DN 160 ISO-K | DN 160 CF |
| Pumping speed | ||||
| N2 | 300 l/s | 365 l/s | ||
| Ar | 260 l/s | 330 l/s | ||
| He | 260 l/s | 280 l/s | ||
| H2 | 190 l/s | 200 l/s | ||
| Operating speed | 58,800 min-1 / 58,800 rpm | |||
| Compression ratio | ||||
| N2 | 1.0 x 1010 | |||
| H2 | 3.2 x 103 | |||
| He | 9.2 x 104 | |||
| Ultimate pressure mbar / Torr | < 10-8 / < 0.75 x 10-8 | < 10-10 / < 10-10 | < 10-8 / < 0.75 x 10-8 | < 10-10 / < 10-10 |
| Max. degassing temperature | - | 80°C (176°F) | - | 80°C (176°F) |
| Max. foreline pressure for N2 | 8 mbar / 6 Torr | |||
| Recommended backing pump | TRIVAC D 2.5E / TRIVAC D 8 B | |||
| Run up time | < 5 min | |||
| Foreline flange | DN 16 ISO-KF - clamped | |||
| Purge / vent port | ||||
| Water cooling connection | G 1/8" inside thread | |||
| Weight | 12 kg / 26 lbs | |||
| Power supply | 48 V | |||
| Ripple | < 2% | |||
| Max. power consumption | 400 W | |||
| Power consumption at ultimate pressure | 259 W | |||
| Max. DC current consumption | 7.5 to 9.3 A | |||
| DC power supply voltage range | 43 to 53 V | |||
| Max. contact rating for the relays | 32 V / 0.5 A | |||
| Permissible ambient temperature during operation | +10 to +40°C (+50 to +104°F) | |||
| Permissible ambient temperature during storage | 0 to +60°C (0 to +140°F) | |||
| Relative humidity of the air, non-condensing | 5 to 85% | |||
| Protection class | IP 30 | |||
| Overvoltage category | II | |||
| Pollution category | 2 | |||
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold MAG W 300 - 700 iP - REBUILT | Download |
Need modifications to this item? PTB Sales engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC MAG W 400 iP Turbomolecular Pump - REBUILT Part no. 410400V0505 Pumping speed: 365 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 16 ISO-KF (clamped) convection-cooled Part no. 410400V0506 Pumping speed: 365 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 160 CF Connecting flange fore-vacuum: DN 16 ISO-KF (clamped) convection-cooled Leybold Vacuum TURBOVAC MAG W 400 iPL Turbomolecular Pump - REBUILT Part no. 410400V0715 Pumping speed: 365 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 16 ISO-KF (clamped) convection-cooled
