Leybold TURBOVAC MAG W 600 / 700 iP - NEW
Call for Price
In stock
Only %1 left
SKU
NEW_MAGW600/700iP
| Weight | 37.50 lbs |
|---|---|
| Pumping Speed | 590 l/s |
| Ultimate Pressure | < 1 x 10-10 mbar |
Leybold TURBOVAC MAG W 600 / 700 iP Turbomolecular Vacuum Pump - NEW
Accuracy, precision and reliability those are the features of these magnetically-levitated turbomolecular pumps. High pumping speed and gas throughput for faster pump down time improve equipment cycle times. With its fully integrated converter and power supply, conventional rack-mounted controller and interconnecting cables are no longer necessary.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| TURBOVAC | MAG W 600 iP | MAG W 700 iP | ||
|---|---|---|---|---|
| Inlet flange | DN 160 ISO-K | DN 160 CF | DN 200 ISO-K | DN 200 CF |
| Pumping speed | ||||
| N2 | 550 l/s | 590 l/s | ||
| Ar | 520 l/s | 540 l/s | ||
| He | 570 l/s | 600 l/s | ||
| H2 | 410 l/s | 430 l/s | ||
| Operating speed | 48,000 min-1 / 48,000 rpm | |||
| Compression ratio | ||||
| N2 | 1.6 x 1010 | |||
| H2 | 3.4 x 104 | |||
| He | 1.7 x 106 | |||
| Ultimate pressure mbar / Torr | < 10-8 / < 0.75 x 10-8 | < 10-10 / < 0.75 x 10-10 | < 10-8 / < 0.75 x 10-8 | < 10-10 / < 0.75 x 10-10 |
| Max. degassing temperature | - | 80°C (176°F) | - | 80°C (176°F) |
| Max. foreline pressure for N2 | 6 mbar / 4.5 Torr | |||
| Recommended backing pump | TRIVAC D 2.5E / TRIVAC D 8 B | |||
| Run up time | < 6 min | |||
| Foreline flange | DN 25 ISO-KF - clamped | |||
| Purge / vent port | ||||
| Water cooling connection | G 1/8" inside thread | |||
| Weight | 17 kg / 37.5 lbs | |||
| Power supply | 48 V | |||
| Ripple | < 2% | |||
| Max. power consumption | 400 W | |||
| Power consumption at ultimate pressure | 259 W | |||
| Max. DC current consumption | 7.5 to 9.3 A | |||
| DC power supply voltage range | 43 to 53 V | |||
| Max. contact rating for the relays | 32 V / 0.5 A | |||
| Permissible ambient temperature during operation | +10 to +40°C (+50 to +104°F) | |||
| Permissible ambient temperature during storage | 0 to +60°C (0 to +140°F) | |||
| Relative humidity of the air, non-condensing | 5 to 85% | |||
| Protection class | IP 30 | |||
| Overvoltage category | II | |||
| Pollution category | 2 | |||
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold High Vacuum - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TURBOVAC MAG W 600 / 700 iP Turbomolecular Vacuum Pump - NEW TURBOVAC MAG W 600 iP Part no. 410600V0505 Pumping speed: 550 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 25 ISO-KF (clamped) convection-cooled TURBOVAC MAG W 600 iP Part no. 410600V0506 Pumping speed: 550 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 160 CF Connecting flange fore-vacuum: DN 25 ISO-KF (clamped) convection-cooled TURBOVAC MAG W 700 iP Part no. 410700V0505 Pumping speed: 590 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 200 ISO-K Connecting flange fore-vacuum: DN 25 ISO-KF (clamped) convection-cooled TURBOVAC MAG W 700 iP Part no. 410700V0506 Pumping speed: 590 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 200 CF Connecting flange fore-vacuum: DN 25 ISO-KF (clamped) convection-cooled
