Leybold TURBOVAC MAG W 600 iP - REBUILT
Starting at
$11,800
In stock
Only %1 left
SKU
REBUILT_MAGW600IP
| Weight | 37.5 lbs |
|---|---|
| Pumping Speed | 550 l/s |
| Ultimate Pressure | 1 x 10-8 mbar |
Leybold Vacuum TURBOVAC MAG W 600 iP Turbomolecular Pump - REBUILT
Accuracy, precision and reliability those are the features of these magnetically-levitated turbomolecular pumps. High pumping speed and gas throughput for faster pump down time improve equipment cycle times. With its fully integrated converter and power supply, conventional rack-mounted controller and interconnecting cables are no longer necessary.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| MAG W 600 iP | 410600V0505 | 410600V0506 |
|---|---|---|
| Inlet connection | DN 160 ISO-K | DN 160 CF |
| Outlet connection | DN 25 ISO-KF - clamped | |
| Pumping speed | ||
| N2 | 550 l/s | |
| Ar | 520 l/s | |
| He | 570 l/s | |
| H2 | 410 l/s | |
| Gas throughput | ||
| N2 | 9.0 mbar x l/s | |
| Compression ratio | ||
| N2 | 1.6 x 1010 | |
| H2 | 1.7 x 106 | |
| He | 3.4 x 104 | |
| Ultimate pressure | < 10-8 mbar / < 0.75 x 10-8 Torr | < 1 x 10-10 mbar / < 7.5 x 10-11 Torr |
| Max. foreline pressure for N2 | 8 mbar / 6 Torr | |
| Nominal rotation speed | 48,000 min-1 / 48,000 rpm | |
| Run up time | ≈ 6 min | |
| Max. power consumption | 400 W | |
| Power consumption at ultimate pressure | 100 W | |
| Protection rating | IP 30 | |
| Admissible ambient temperature | +10 to +40°C +50 to +104°F | |
| Cooling standard | Convection | |
| Cooling optional | Air / water | |
| Cooling water connection | G 1/8" inside thread | |
| Weight | 17 kg / 37.5 lbs | |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold MAG W 300 - 700 iP - REBUILT | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC MAG W 600 iP Turbomolecular Pump - REBUILT Part no. 410600V0505 Pumping speed: 550 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 25 ISO-KF (clamped) convection-cooled Part no. 410600V0506 Pumping speed: 550 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 160 CF Connecting flange fore-vacuum: DN 25 ISO-KF (clamped) convection-cooled Part no. 410600V0525 Pumping speed: 550 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 25 ISO-KF (clamped) water-cooled
