Agilent TriScroll PTS300 Module S4700304 - NEW
| Weight | 70 lbs |
|---|---|
| Motor Power | 1 hp |
| Pumping Speed | 14.8 cfm |
| Ultimate Pressure | 7 x 10-3 Torr |
Agilent TriScroll PTS300 Dry Scroll Vacuum Pump Module - NEW
Agilent Technologies’ unique, patented TriScroll series features two-stage dry scroll pumps that deliver high pumping speeds and low base pressure. The frequent maintenance requirements of oil-sealed rotary vane pumps are eliminated with dry scroll pumps, simplifying regulatory and environmental compliance, and eliminating oil disposal costs. Agilent TriScroll dry scroll pumps feature proven reliability and durability, providing consistent performance and superior cost of ownership.
The TriScroll 600 pump operates at a pumping speed of 500 liters/minute.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Peak pumping speed | 50 Hz: 420 l/m, 25.2 m3/hr (14.8 cfm) 60 Hz: 500 l/m, 30 m3/hr (17.7 cfm) |
| Media | Clean air. No toxic, corrosive, explosive or particulate forming gases |
| Ultimate pressure (Torr) | 7.0 x 10-3 Torr (9.3 x 10-3 mbar) |
| Maximum inlet pressure | 1.0 atmosphere (0 psig) |
| Maximum outlet pressure | 1.1 atmosphere (1.5 psig) |
| Inlet connection | NW40 |
| Exhaust connection | Female 3/8" National Pipe Thread (NW25 adapter provided) |
| Gas ballast | Female 1/4" National Pipe Thread (40 Micron sintered filter provided) |
| Ambient operating temperature | 5°C to 40°C (41°F to 104°F) |
| Storage temperature | -20°C to 60°C (-4°F to 140°F) |
| Motor rating | 1.0 hp (0.76 kW) |
| Operating voltages | Single-phase: 50-60 Hz 100-115:200-230 VAC Three-phase: 50 Hz 200-230:380-415 VAC, 60 Hz 200-230:460 VAC |
| Motor thermal protection | Type U automatic |
| Operating speed | 50 Hz: 1,425 rpm, 60 Hz: 1 |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Agilent Standard replacement pump module, for TriScroll 300 series dry vacuum pump S4700304 TriScroll PTS300 scroll pump module
