Agilent HS 32 - NEW

Call for Price

In stock
Only %1 left
SKU
NEW_HS32
Weight 1500 lbs
Pumping Speed 36656.62 cfm
Ultimate Pressure 1.7 x 10-3 to <5 x 10-8 Torr

Agilent Varian HS-32 Diffusion High Vacuum Pump - NEW

The Agilent HS-32 Oil Diffusion Pump is a pump with high throughput and high pumping speed of 32,000 l/s. With its fully optimized vapor jet, robust boiler design and thermal protection switches, the pump will run without any maintenance for many years. It is available with 32 in. ASA or ISO 800F (bolted) inlet flange.

This pump is a perfect fit for industrial applications such as vacuum furnace, heat treatment, metallizing, and coating processes for optical lenses, electronics and protective film layers.

  • Five-stage stainless steel fractionating jet purifies pumping fluid
  • Full thermal protection
  • Fluid-level sight glass provides quick indication of pump fluid level at all times. Fill and drain assembly for pump oil.
  • Optional halo baffle cold cap reduces backstreaming without adding height
  • Standard gauge port (NW-25) below inlet flange included
  • Optional quick cool coil
  • Please note that this item is controlled for export by the Nuclear Suppliers Group. Accordingly, you may be required to obtain an export license from the U.S. Department of Commerce prior to exporting this pump from the United States. Please consult the U.S. Export Administration Regulations, ECCN 2B231, for further guidance.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Backstreaming Rate
  • 7 x 10-4 mg/cm²/min
Cooldown Time
  • 60 min
Electrical Requirements
  • 3 ph
  • 50/60 Hz
  • 240/415/480 V
Fluid Charge
  • 11356 CC
Fluid Type
  • Oil
Input Voltage
  • 240, 415, 480 V
Maximum Forepressure - Full Load
  • 0.35 Torr
  • 0.45 mbar
Maximum Forepressure - No Load
  • 0.50 mbar
  • 0.65 mbar
Maximum Throughput
  • 30 T-L/s (40 mbar-L/s)
Operating Range
  • 1.7 x 10-3 to <5 x 10-8 Torr
  • 2.3 x 10-3 to <6.5 x 10-8 mbar
Pump Power
  • 24000 W
Pump Weight
  • 1500 lbs
  • 680.4 kg
Pumping Speed - Air
  • 17300 L/s
Pumping Speed - Air, via AVS 4.1 (1963)
  • 32000 L/s
Pumping Speed - He/H2
  • 21625 L/s
Recommended Backing Pump
  • ≥ 300 cfm (510 m3/hr)
Warmup Time
  • 60 min
Water Connections
  • 3/8 inch FPT
Water Cooling - Temperature Requirement
  • 60-80 °F
  • 15-26 °C
Water Cooling Flow Requirement
  • 4.0 gpm
  • 800 L/hr

Specifications

Type Label Description Download
Agilent HS & NHS Series - NEW Instruction Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Agilent Varian HS-32 Diffusion High Vacuum Pump - NEW

76134308 / 76134-308  ASA w/ standard cold cap 240V
76134318 / 76134-318  ASA w/ halo baffle 240V
76134326 / 76134-326  ASA w/ standard cold cap 415V
76134336 / 76134-336  ASA w/ halo baffle 415V
76134309 / 76134-309  ASA w/ standard cold cap 480V
76134319 / 76134-319  ASA w/ halo baffle 480V
L5923308 / L5923-308  ISO w/ standard cold cap 240V
L5923318 / L5923-318  ISO w/ halo baffle 240V
L5923326 / L5923-326  ISO w/ standard cold cap 415V
L5923336 / L5923-336  ISO w/ halo baffle 415V
L5923309 / L5923-309  ISO w/ standard cold cap 480V
L5923319 / L5923-319  ISO w/ halo baffle 480V
