Agilent TwisTorr 305 FS - NEW

Starting at $11,301
In stock
Only %1 left
SKU
NEW_TwisTorr305FS
Weight 12.87 lbs
Pumping Speed 250 l/s
Ultimate Pressure < 1 x 10-10 mbar

Agilent TwisTorr 305 FS Turbomolecular Vacuum Pump - NEW

The TwisTorr 305 FS turbomolecular pump features an entirely new design and advanced connectivity options such as Bluetooth. This 300 l/s turbo pump can be driven wirelessly using the Vacuum Link app. The TwisTorr 305 FS turbo pump is ideal for academic research and industrial applications where compression ratio is an important factor. The pump’s low noise and vibration features make it a perfect solution for sensitive instruments, like electron microscopes and surface analysis.

  • Low noise levels - 41 dB(A) at full speed
  • High compression ratios for light gases
  • Compact size
  • Smart power management
  • Oil-free solution
  • Low-maintenance cost
  • Multiple configurations available for various flange sizes and air/water cooling
  • Two controllers are available to drive the pump operation
  • Full range of accessories

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Ambient Operating Temperature
  • +5 to +35 °C
Ambient Storage Temperature
  • -40 to +70 °C
Base Pressure
  • <1*10-10 mbar
Compression Ratio H2
  • 1.5 x 106
FlangeType
  • DN 100
  • DN 160
Foreline Flange Size
  • KF 16 NW
Foreline Tolerance - N2
  • 12 mbar
Maximum Gas Throughput - N2, Water Cooling
  • 250 sccm
Noise Level
  • 41 dB(A)
Nominal Rotation Speed
  • 60 KRPM
Operating Position
  • Any
Pumping Speed - Ar
  • 250 l/s
Pumping Speed - H2
  • 220 l/s
Pumping Speed - He
  • 255 l/s
Pumping Speed - N2
  • 250 l/s
Recommended Forepump Capacity
  • 7 m³/h
Standards and Certifications
  • EN 61010-1
    EN 61326-1
    EN 1012-2
    EN 12100
    EN 50581
    Machinery Directive 2006/42/EC
    Electromagnetic Compatibility Directive 2014/30/
    EU Directive 2011/65/EU
Start Up Time
  • < 3 min
Weight
  • 5.84 kg

Specs

Type Label Description Download
Agilent TwisTorr 305 - NEW Instruction Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Agilent TwisTorr 305 FS Turbomolecular Vacuum Pump - NEW

X351364008 / X3513-64008  ISO-100K air cooling
X351364009 / X3513-64009  CFF-6 air cooling
X351364010 / X3513-64010  ISO-160K air cooling
X351364011 / X3513-64011  CFF-8 air cooling
X351364012 / X3513-64012  ISO-100K water cooling
X351364013 / X3513-64013  CFF-6 water cooling
X351364014 / X3513-64014  ISO-160K water cooling
X351364015 / X3513-64015  CFF-8 water cooling
