Agilent Varian VS BR15 - REBUILT
Agilent Varian VS BR15 Mass Spectrometer Bench Mount Helium Leak Detector - REBUILT
This product can be purchased or rented. Click the "RFQ" button to specify your needs.
Features & Benefits
- Fully automated start-up and calibration maximizes productivity
- Programmable test sequences improves testing efficiency
- Color touch screen provides excellent clarity, even at wide angles
- High test port pressure allows for detection of large leaks
- 12-range MDL (helium sensitivity) meets the most stringent leak test requirements
- New high efficiency ion source and beam optics optimize sensitivity and mass separation
- Robust Faraday cup technology delivers proven reliability with low cost of ownership
- Allows testing of large systems by a single operator
- Leak detector can be located outside cleanroom to prevent contamination
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Specifications |
Bench Top |
Bench Mount or Mobile |
| Model # |
PR02, PD03 |
MR15, MD30, BR15, BD30 |
| Rotary vane pump |
DS-42 2 m3/hr (34 l/m) |
DS-302 14 m3/hr (232 l/m) |
| Dry scroll pump |
N/A |
TS-620 30 m3/hr (500 l/m) |
| Minimum detectable leak at 1,000 ppm ambient He |
5 x 10-12 atm cc/sec : 5 x 10-12 mbar l/s : 5 x 10-13 Pa m3/sec helium |
| Maximum test port pressure |
13 mbar, 10 Torr, 1,330 Pa |
| Helium pumping speed @ test port (fine test) |
1.8 l/s |
| Calibration routine |
Automated or manual (internal or external) |
| Background suppression |
Push button initiated auto zero, and auto zero < zero function |
| User interface |
High clarity, color display, TFT touch screen |
| Selectable languages |
English, French, German, Japanese, Korean, Mandarin, Spanish |
| Automated cycling |
Programmable rough time, test time, reject set points |
| Response time |
< 0.5 seconds |
| Set points |
Standard, 5 set points, N/O or N/C; 3 leak rate, 1 pressure, 1 audio |
| Serial interface |
RS-232 optically-isolated interface @ 9,600 baud (DB-9S) |
| Discrete I/O |
Optically isolated, 5-24 volts VDC outputs and inputs (DB-25S) |
| Wireless remote control (optional) |
2.4 GHz ISM band, 100m (328 ft) range, 4 AA batteries or 5 VDC supply |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Agilent Varian VS BR15 Mass Spectrometer Bench Mount Helium Leak Detector - REBUILT
VS BR15 VSBR151 100/115 VAC DS302 external
VS BR15 VSBR152 230 VAC DS302 external
