Agilent VS MD30 - REBUILT
Agilent Varian VSMD30 Mass Spectrometer Mobile Helium Leak Detector - REBUILT
Agilent Technologies leak checkers can be purchased or rented. Click the "RFQ
Features & Benefits
Fully automated start-up and calibration maximizes productivity
Programmable test sequences improves testing efficiency
Color touch screen provides excellent clarity, even at wide angles
High test port pressure allows for detection of large leaks
12-range MDL (helium sensitivity) meets the most stringent leak test requirements
New high efficiency ion source and beam optics optimize sensitivity and mass separation
Robust Faraday cup technology delivers proven reliability with low cost of ownership
Allows testing of large systems by a single operator
Leak detector can be located outside cleanroom to prevent contamination
Questions? send an email to our sales team!
Specifications
VS MD15
VS MD30+
Fore pump type
IDP-15
TS-620
Pump speed 50/60 Hz
250/210 l/min
500/420 l/min
Minimum detectable leak
5 x 10-12 atm cc/sec
Internal pump version
DS-42 / IDP-3
Turbomolecular pump
Navigator™ turbomolecular pump specifically designed for leak detection
Leak units
atm-cc/sec, mbar-l/sec, torr-l/sec, Pa-m3 /sec, std. ft3 /year
Peak pumping speed
Contra w/ DS42 – 0.5 l/sec for N2 and He at 60 Hz in Contra (.42 l/sec @ 50 Hz)
Contra w/ DS302 – 3.0 liters/sec for N2 and He at 60 Hz (2.5 l/sec @ 50 Hz)
Contra w/ TS620 – 6.0 liters/sec for N2 and He at 60 Hz (5.0 l/sec @ 50 Hz)
Contra w/ IDP-3 - 6.0 l/sec (60 Hz), 5.0 l/sec (50 Hz)
Midstage – 1.8 liters/sec for He at 50 or 60 Hz
Helium response time
0.5 second, within 66% of peak reading within the given time. Per AVS 2.1
Test port
NW-25; A 11/8" (28 mm) ID Compression Port is available as an accessory
Recommended Operating Ambient Conditions
Installation
Indoor use only. Altitude up to 2000 m (6,400’), Material Group III, POLLUTION DEGREE 2 according to EN61010-1 Standard, Class 1
Operating temperature
System: +12° C to +45° C (wet and dry pumps); Fore pump limited on the low ends and turbo pump limited on the high ends
Humidity
Maximum relative humidity (HR) 90%
Heat load
1,000 W (+/- 5%)
Air pressure
563 Torr (75 kPa) to 795 Torr (106 kPa)
Maximum system vibration
3 G’s (turbo limit)
Storage ambient conditions
Relative humidity: 0% to 95%, non-condensing. Temperature: -20°C (-4°F) to +60°C (140°F)
Power requirements
Input power
100 VAC, 50 Hz, 20 A
115 VAC, 60 Hz, 20 A or
230 VAC, 50/60 Hz, 12 A
Max. branch circuit breaker: 20A with motor-rated time delay
Weight
98 kg
96 kg
LCD display
Size = 112 mm x 150 mm, overall, 90 mm x 115 mm viewing area (HxW) Color, ¼ VGA (320 x 240), backlit
Regulatory
Safety:
Low Voltage Directive (LDV) 73/23/EEC:1973 as Amended by 93/68/EEC:1993 EMC:
Electromagnetic Compatibility (EMC) Directive 89/336/EEC:1989 as Amended by 93/68/EEC:1993
Radio and Telecommunication Terminal Equipment (R&TTE) Directive, 1999/5/EC: 1999
For particular Safety and EMC Standards see Declaration of Conformity
Single rotation speed
Turbo: 70K rpm
Leak test range
E-11 to E-4
Maximum spectrometer pressure
1E-04 Torr - Filament turns off when pressure exceeds this point
Contra cross over
10 Torr decreasing, 12 Torr increasing
Sensitivity in high pressure test mode
1 x 10-8 atm.cc.sec
Type
Label
Description
Download
Agilent VS Series - REBUILT
Operations Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Agilent Varian VS MD15 / MD30+ Mass Spectrometer Mobile Helium Leak Detector - REBUILT
VS MD15 G8601-64004 100/115 VAC IDP-15 external
VS MD15 G8601-64005 230 VAC IDP-15 external
VS MD30 VSMD301 100/115 VAC PTS600 external
VS MD30 VSMD302 230 VAC PTS600 external
VS MD30+ VSMD301 100/115 VAC TS620 external
VS MD30+ VSMD302 230 VAC TS620 external
These helium leak detectors may have options:
Wireless Remote, Base Unit: VSFACWB, VSFLDWB
I/O board with flapper box cable: VSFACIO, VSFLDIO
Leak Test Data Wizard Software: VSLTDW
11/8 in. Compression Test Port (N2 vent hardware): VSFLDCP
