Edwards EV160 - REBUILT
Call for Price
| Weight | 342 lbs |
|---|---|
| Motor Power | 5.5 hp |
| Pumping Speed | 160 m3/h |
| Ultimate Pressure | 5 x 10-1 mbar |
Edwards EV160 Oil Sealed Rotary Vane Vacuum Pump - REBUILT
The EV rotary vane pumps are designed to be used in a wide range of industrial and scientific applications. They can be used individually or with mechanical booster pumps to increase both performance and ultimate vacuum. They can operate continuously from atmosphere to ultimate.
With reliability and ease of service in mind, the EV range of pumps are designed for the industrial and scientific markets. Edwards Applications Specialists have unrivalled knowledge and can advise on pump selection, configuration and operation to suit any customers’ requirements. The EV range can be supplied individually or as part of pre-engineered combinations using either Edwards EH mechanical boosters.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Pumping speed 50 Hz | 160 m3h-1 / 96 ft3min-1 |
| Pumping speed 60 Hz | 192 m3h-1 / 116 ft3min-1 |
| Ultimate pressure w/o gas ballast | 0.5 mbar |
| Water vapor capacity | 1.2 kg h-1 @ 10 mbar / 2.6 lb h-1 @ 10 mbar |
| Electricity supply 50 Hz | 190 - 255 / 330 - 440 V |
| Electricity supply 60 Hz | 190 - 290 / 330 - 500 V |
| Motor power 50 Hz | 4 kW / 5.5 hp |
| Motor power 60 Hz | 4.8 kW / 6.5 hp |
| Noise 50 Hz | 71 dB(A) |
| Noise 60 Hz | 74 dB(A) |
| Weight | 155 kg / 342 lbs |
| Oil capacity | 7 litre / 1.84 US gal |
| Oil type | UG20 |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards EV Series - REBUILT | Installation & Operating Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards EV160 Oil Sealed Rotary Vane Vacuum Pump - REBUILT
