Edwards iGX600N - REBUILT
Call for Price
| Weight | 485 lbs |
|---|---|
| Pumping Speed | 600 m3/h |
| Ultimate Pressure | 7 x 10-4 mbar |
Edwards iGX600N Semiconductor Dry Vacuum Pump - REBUILT
The iGX dry vacuum pump series sets new standards for zero maintenance between major overhauls. Improved efficiency lowers the cost of ownership and provides continuous pumping duty throughout the pressure range.
iGX dry pumps include Ethernet connectivity allowing key data to be viewed via web pages, as well as a comprehensive set of networking options to assure continuous pump availability.
iGX pumps are available in a wide range of peak speeds and variants to address applications from clean through to medium-duty processes. A modular design allows users to configure iGX drypumps to suit individual fab requirements. An ultra-compact footprint allows installation options including on-tool, close proximity, or remote.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Peak speed | 600 m3h-1 |
| 365 cfm | |
| 10,333 l min-1 | |
| Ultimate pressure | 7.00E-04 mbar |
| 5.25E-04 Torr | |
| 0.07 Pa | |
| Power at 700 Torr exhaust | |
| Ultimate | 1.6 kW |
| AUC (Active Utility Controller) | 0.05 kW |
| Water inlet* | 2 slm |
| Nitrogen | 4 or 14 slm |
| Footprint excluding exhaust | 0.20 m2 |
| Weight | 220 kg |
| Inlet connection | ISO100 |
| Outlet connection | NW25 |
| Noise at ultimate | < 55 dB(A) |
* Requires constant flow valve accessory.
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards iGX Series - REBUILT | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards iGX600N Semiconductor Dry Vacuum Pump - REBUILT A54631958 / A546-31-958 iGX600N 200-230V 50/60Hz A54631959 / A546-31-959 iGX600N 380-460V 50/60Hz A53620958 / A536-20-958 iGX3/100L 200-230V 50/60Hz A53620959 / A536-20-959 iGX3/100L 380-460V 50/60Hz A53630958 / A536-30-958 iGX6/100L 200-230V 50/60Hz A53630959 / A536-30-959 iGX6/100L 380-460V 50/60Hz A53621958 / A536-21-958 iGX3/100N 200-230V 50/60Hz A53621959 / A536-21-959 iGX3/100N 380-460V 50/60Hz A53631958 / A536-31-958 iGX6/100N 200-230V 50/60Hz A53631959 / A536-31-959 iGX6/100N 380-460V 50/60Hz A53622958 / A536-22-958 iGX3/100M 200-230V 50/60Hz A53622959 / A536-22-959 iGX3/100M 380-460V 50/60Hz A53632958 / A536-32-958 iGX6/100M 200-230V 50/60Hz A53632959 / A536-32-959 iGX6/100M 380-460V 50/60Hz A53681958 / A536-81-958 iGX10/100N 200-230V 50/60Hz A53681959 / A536-81-959 iGX10/100N 380-460V 50/60Hz
