Edwards nEXT55 - NEW
Starting at
$0
In stock
Only %1 left
SKU
NEW_nEXT55
| Weight | 9.5 lbs |
|---|---|
| Pumping Speed | 55 l/s |
| Ultimate Pressure | < 5 x 10-9 mbar |
Edwards nEXT55 Compound Turbomolecular Vacuum Pump - NEW
The nEXT55 is one of the most compact of the nEXT range, with a significantly reduced height and improved performance in a smaller package these pumps offer pumping speeds of 55 l/s for nitrogen, they offer the highest pumping density of other pumps in its class by far, with almost double the pumping speed of similar sized turbo pumps.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Connection Vacuum Inlet Flange | DN 40 ISO-KF (NW40) |
| Noise Level | 34.00 db(A) |
| Supply Frequency | DC Voltage |
| Cooling Method | Air Cooling (convection) Air Cooling (forced - fan) |
| Connection vacuum outlet flange | DN 16 ISO-KF (NW16) |
| Supply Voltage | DC 24V |
| IP Rating | IP64 |
| Connection Cooling | 1/8" BSPP (G) Female |
| Connection Power | DSUB 15-PIN - Male (flying lead 300 mm) |
| Connection Purge Gas Ballast & Vent Connector | 1/8" BSPP (G) Female |
| Recommended Controller | TIC / TAG |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards nEXT 55/85 - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards MODEL: nEXT55 Compound Turbomolecular Vacuum Pump - NEW
CODE: B8E2-10-101 / B8E210101 nEXT55D DN 100 ISO-K NW16 80W
CODE: B8E2-10-A01 / B8E210A01 nEXT55D DN 40 ISO-KF (NW40) NW16 80W
CODE: B8E2-10-B01 / B8E210B01 nEXT55D DN 63 ISO-K NW16 80W
B8E2-10-C01 / B8E210C01 nEXT55D DN 63 CF (4.5") NW16 80W
