Edwards nHT10 - NEW
Call for Price
In stock
SKU
NEW_nHT10
| Weight | 231.5 lbs |
|---|---|
| Pumping Speed | 3,000 l/s |
| Ultimate Pressure | < 5 x 10-7 mbar |
Edwards nHT10 Vapour Diffusion Vacuum Pump - NEW
Edwards nHT series diffusion pumps provide stable high throughput vacuum performance. Designed for optimum energy efficiency, flexibility and low maintenance, the nHT series is the ideal solution for a variety of demanding industrial applications.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| ANSI | ISO | |
| Inlet | 10 in ANSI | 320 ISO-K |
| Backing connection | 2 in ANSI | 63 ISO-K |
| Pumping speed | ||
| N2 | 3,000 l/s | |
| H2 | 4,500 l/s | |
| Ar | 2,750 l/s | |
| Gas Throughput | 8 mbar l/s | |
| Operating range | 10-1 to 10-7 | |
| Ultimate pressure (Edwards 704) | < 5 x 10-7 mbar | |
| Critical backing pressure (Edwards 704) | 5 x 10-1 mbar | |
| Heating power | 3.6 kW | |
| Heating cartridges | 3 | |
| Warm-up period | Less than 15 minutes | |
| Weight | 105 kg | |
| Recommended oil | Edwards 704 | |
| Oil | 3.0 - 4.0 l | |
| Recommended holding pump | E2M40 | |
| Recommended backing pump | E2M80, GV80 |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards nHT Series - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards nHT10 Vapour Diffusion Vacuum Pump - NEW B31130400 / B311-30-400 nHT10 ANSI 380-415V, 230V B31132400 / B311-32-400 nHT10 ISO 380-415V, 230V B31130460 / B311-30-460 nHT10 ANSI 440-480V, 230V B31132460 / B311-32-460 nHT10 ISO 440-480V, 230V
