Edwards nHT32 - NEW
Call for Price
In stock
SKU
NEW_nHT32
| Weight | 1256.50 lbs |
|---|---|
| Pumping Speed | 21,000 l/s |
| Ultimate Pressure | < 1 x 10-6 mbar |
Edwards nHT32 Vapour Diffusion Vacuum Pump - NEW
Edwards nHT series diffusion pumps provide stable high throughput vacuum performance. Designed for optimum energy efficiency, flexibility and low maintenance, the nHT series is the ideal solution for a variety of demanding industrial applications.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| nHT32 | |||
| ANSI | ISO | ||
| Inlet connection | 32” ANSI | 800 ISO-F | |
| Backing connection | 6” ANSI | 200 ISO-K | |
| Pumping speed* Nitrogen <10-4 mbar |
l/s | 21,000 | |
| Pumping speed Argon <10-4 mbar |
l/s | 18,000 | |
| Pumping speed Helium <10-4 mbar |
l/s | 30,000 | |
| Gas throughput | mbar l/s | 36 | |
| Operating range | mbar | <10‐2 to 10‐7 | |
| Ultimate pressure (Edwards 704) | mbar | < 10‐6 | |
| Critical backing pressure (Edwards 704) | mbar | 5 x 10-1 | |
| Heating power | kW | 21.6 | |
| Heating cartridges | qty | 18 | |
| Warm-up period | min | < 25 | |
| Weight | 570 | ||
| Recommended oil | Edwards 704 | ||
| Oil | L | 9.0–11.0 | |
| Recommended holding pump | E2M80 | ||
| Recommended backing pump | nES630, E2M275, GXS450, EH2600 |
||
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards nHT Series - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards nHT32 Vapour Diffusion Vacuum Pump - NEW B31430400 / B314-30-400 nHT20 ANSI 380-415V, 230V B31432400 / B314-32-400 nHT20 ISO 380-415V, 230V B31430460 / B314-30-460 nHT20 ANSI 440-480V, 230V B31432460 / B314-32-460 nHT20 ISO 440-480V, 230V
