Edwards T-Station 85H Wet - NEW
Call for Price
| Weight | 47 lbs |
|---|---|
| Pumping Speed | 47-84 l/s |
| Ultimate Pressure | < 5 x 10-8 mbar |
Edwards T-Station 85H Wet Turbomolecular Vacuum Pumping Station - NEW
The T-Station 85 turbomolecular pumping station seamlessly combines an nEXT85H turbomolecular pump with either a dry diaphragm pump or oil sealed backing pump and a simple controller, providing pumping speeds of 47 l/s to 84 l/s.
The T-Station 85 comes with an integrated Turbo and Active Gauge controller which enables single button start/stop of the system, the ability to control one of our active gauges*, vent valve* control and delayed start of the turbomolecular pump to either time or pressure if a gauge is fitted, making the T-Station 85 ideal for general laboratory needs.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Pumping speed for N2 | |
| NW-40 | 47 l/s |
| ISO / CF-63 | 84 l/s |
| Compression ratio for N2 | > 1 x 1011 |
| Backing pump speed 50/60 Hz | |
| E2M1.5 | 1.6 m3hr-1 (1.2 cfm) |
| Ultimate pressure | < 5 x 10-8 mbar |
| Inlet flange | NW-40, ISO-63, CF-63 |
| Exhaust flange | |
| E2M1.5 | NW-16 |
| Mass | |
| E2M1.5 | 21 kg |
| Noise level | ≤ 56 dB(A) |
| Leak tightness | < 1 x 10-6 mbar l/s |
| Operating temperature range | 12 to 40°C |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards T-Station 85 - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards T-Station 85H Wet Turbomolecular Vacuum Pumping Station - NEW TS85W1001 / TS85-W1-001 T-Station 85H Wet NW-40 200-240V TS85W2001 / TS85-W2-001 T-Station 85H Wet ISO-63 200-240V TS85W3001 / TS85-W3-001 T-Station 85H Wet CF-63 200-240V TS85W1002 / TS85-W1-002 T-Station 85H Wet NW-40 100-120V TS85W2002 / TS85-W2-002 T-Station 85H Wet ISO-63 100-120V TS85W3002 / TS85-W3-002 T-Station 85H Wet CF-63 100-120V
