INFICON UL 1000 Fab - REBUILT
Call for Price
INFICON UL 1000 Fab ULTRATEST Helium Mass Spectrometer Leak Detector - REBUILT
The INFICON UL 1000 mobile helium leak detector is designed to meet the most demanding industrial leak detection applications. Providing fast, accurate and repeatable test results, testing flexibility, and high sensitivity in a low maintenance design, the UL 1000 is ready to tackle the toughest leak detection jobs industry can offer. The UL 1000 is optimized to provide quick, accurate results in any application from the leak checking of large vessels and systems to high-cycle, repetitive component testing - 24 hours / 7 days a week - in the toughest industrial environments.
Ask about the dry scroll optional.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Min. Detectable leak rate for helium (Vacuum mode) | <5E-12 mbar•l/s |
| Min. detectable leak rate for Helium (Sniffer mode) | 5E-8 mbar•l/s |
| Max. Inlet pressure GROSS mode | 15 mbar |
| Max. Inlet pressure FINE mode | 2 mbar |
| Max. Inlet pressure ULTRA mode | 0.4 mbar |
| Pumping speed during evacuation | 16 m3/h at 50 Hz |
| Helium pumping speed GROSS mode | 8 l/s max. |
| Helium pumping speed FINE mode | 7 l/s |
| Helium pumping speed ULTRA mode | 2.5 l/s |
| Detectable masses | 2, 3, 4 amu |
| Mass spectrometer Sector field | 180° |
| Filaments ion soure Iridium/Yttria coated | 2 |
| Calibrated built in test leak | E-7 mbar•l/s |
| Adjustable triggers | 2 |
| Interface | RS232 |
| Chart recorder output | 2 x 10 V |
| In/Outputs | PLC compatible |
| Permissable ambient temperature (during operation) | +10.....+40°C |
| Type of protection | IP 20 |
| Weight | 110 kg / 242 lb. |
| Dimensions (L x W x H) | 1,068 x 525 x 850 mm / 42 x 21 x 33 in. |
| Supply voltages | 230 V (AC) (+-10%) 50Hz |
| Power consumption | 1,100 VA |
| Type | Label | Description | Download |
|---|---|---|---|
|
INFICON UL 1000 - REBUILT | Technical Handbook | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
INFICON UL 1000 Fab ULTRATEST Helium Mass Spectrometer Leak Detector - REBUILT 550100A / 550-100A UL 1000 Fab 230 V, EU mains plug 550101A / 550-101A UL 1000 Fab 115 V, US mains plug 550000A / 550-000A UL 1000 230 V, EU mains plug 550001A / 550-001A UL 1000 115 V, US mains plug 550002A / 550-002A UL 1000 100 V AC, US mains plug
