Kinney KVA 40 - NEW

Call for Price

In stock
Only %1 left
SKU
NEW_KVA40
Weight 117 lbs
Motor Power 2 hp
Pumping Speed 24 cfm
Ultimate Pressure 1.2 x 10-1 Torr

Kinney KVA 40 Rotary Vane Vacuum Pump - NEW

KVA oil-flooded, multi-vane vacuum pumps are single stage, air cooled and direct driven. This simple design ensures the reliability and the durability that is required in the vacuum industry. The performance of the KVA rotary vane vacuum pump has been optimized to provide even deeper vacuum levels than before. Most models can achieve ultimate pressure levels near 0.1 mbar.

Features

  • Non-metallic vanes
  • Oil level sight glass
  • Vibration isolators
  • Anti-suck back valve
  • Integral exhaust filters
  • TEFC high efficiency motor
  • Available with single-phase motors
  • Models KVA 25-630 include spin-on oil filter

The KVA has been engineered to provide convenient service access to both the oil and filters. Its direct-coupled and air-cooled design requires very little additional maintenance. The small footprint of the KVA pump allows for maximized tabletop and floor space. A smooth and quiet operation can be expected due to the intentional pump design and vibration isolation.

Motor Power (hp): 2

Ultimate Pressure (Torr): 0.12

Pumping Speed (cfm): 28

Kinney is now part of MD-Kinney, which was formerly known as Tuthill Springfield.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Nominal Displacement

    50 Hz

40 m3/h / 24 cfm

    60 Hz

48 m3/h / 28 cfm

Ultimate pressure

0.16 mbar / 0.12 Torr

TEFC Motor

2 hp

Rotational speed

60 Hz: 1,740 rpm

Noise level at 60 Hz

67 dBA

Oil Capacity

1.5 qt / 1.4

Connections



    Inlet NPT

11/4""

    Outlet NPT

11/4""

Weight

117 lbs / 53 kg

Specifications

Type Label Description Download
Kinney KVA Series - NEW OPERATOR’S MANUAL Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
