Leybold BMH70 Turbo Dry - REBUILT

Name: Leybold BMH70 Turbo Dry - REBUILT
Brand: Leybold
SKU: REBUILT_BMH70

Be the first to review this product

Call for Price

In stock

SKU

REBUILT_BMH70

Request For Quote

Weight	30 lbs

Description

Leybold BMH70 Turbomolecular Dry HV Vacuum Pump System - REBUILT

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Specification

BMH70	Basic Version	Full-featured Version
Integrated gauge display	No	Yes
Standard inlet sensor	Optional	Power ITR 90 inlet sensor (atm - 10^-10 Torr) w/ display on system controller
Optional inlet sensor	Power ITR 90 inlet sensor (atm - 10^-10 Torr) w/ integral LCD display	N/A
Optional foreline sensor	N/A	Power TTR 90 inlet sensor (atm - 5 x 10^-4 Torr) w/ display on system controller
System control	Manual	Automatic control (one button) or manual
Vent valve control
TW main status display	Start, Accel., Norm. Op., Decel., Stop
TW operating parameters display	Speed, Temps, Current Draw, etc.

RFQ/Configuration

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Leybold BMH70 Turbomolecular Dry HV Vacuum Pump System - REBUILT

170000       BMH70  TW70H/DIVAC,F/F,CF63
170010       BMH70  DRY,BASIC,ISO63,W/GATE
170034       BMH70  FF,ISO,NO IG,FG,NO TURBO
180000V1000  BMH70  BASIC,ISO,NO IG Turbo Pump
180000V1001  BMH70  BASIC,ISO,NO IG,VV-NC
180000V1100  BMH70  BASIC,ISO,IG/KF/D
180000V1101  BMH70  BASIC,ISO,IG/KF/D,VV-NC
180000V1300  BMH70  BASIC,ISO,IG/CF/D
180000V1301  BMH70  BASIC,ISO,IG/CF/D,VV-NC
180000V2000  BMH70  BASIC,CF,NO IG Turbo Pump
180000V2001  BMH70  BASIC,CF,NO IG,VV-NC
180000V2100  BMH70  BASIC,CF,IG/KF/D
180000V2101  BMH70  BASIC,CF,IG/KF/D,VV-NC
180000V2300  BMH70  BASIC,CF,IG/CF/D
180000V2301  BMH70  BASIC,CF,IG/CF/D,VV-NC
180001V1000  BMH70  FF,ISO,NO IG,NO FG
180001V1010  BMH70  FF,ISO,NO IG,FG
180001V1011  BMH70  FF,ISO,NO IG,FG,VV-NC
180001V1100  BMH70  FF,ISO,IG/KF/D
180001V1101  BMH70  FF,ISO,IG/KF/D,VV-NC
180001V1110  BMH70  FF,ISO,IG/KF/D,FG
180001V1111  BMH70  FF,ISO,IG/KF/D,FG,VV-NC
180001V1200  BMH70  FF,ISO,IG/KF/ND
180001V1201  BMH70  FF,ISO,IG/KF/ND,VV-NC
180001V1210  BMH70  FF,ISO,IG/KF/ND,FG
180001V1211  BMH70  FF,ISO,IG/KF/ND,FG,VV-NC
180001V1300  BMH70  FF,ISO,IG/CF/D
180001V1301  BMH70  FF,ISO,IG/CF/D,VV-NC
180001V1310  BMH70  FF,ISO,IG/CF/D,FG
180001V1311  BMH70  FF,ISO,IG/CF/D,FG,VV-NC
180001V1400  BMH70  FF,ISO,IG/CF/ND
180001V1401  BMH70  FF,ISO,IG/CF/ND,VV-NC
180001V1410  BMH70  FF,ISO,IG/CF/ND,FG
180001V1411  BMH70  FF,ISO,IG/CF/ND,FG,VV-NC
180001V2000  BMH70  FF,CF,NO IG,NO FG
180001V2010  BMH70  FF,CF,NO IG,FG
180001V2011  BMH70  FF,CF,NO IG,FG,VV-NC
180001V2100  BMH70  FF,CF,IG/KF/D
180001V2101  BMH70  FF,CF,IG/KF/D,VV-NC
180001V2110  BMH70  FF,CF,IG/KF/D,FG
180001V2111  BMH70  FF,CF,IG/KF/D,FG,VV-NC
180001V2200  BMH70  FF,CF,IG/KF/ND
180001V2201  BMH70  FF,CF,IG/KF/ND,VV-NC
180001V2210  BMH70  FF,CF,IG/KF/ND,FG
180001V2211  BMH70  FF,CF,IG/KF/ND,FG,VV-NC
180001V2300  BMH70  FF,CF,IG/CF/D
180001V2301  BMH70  FF,CF,IG/CF/D,VV-NC
180001V2310  BMH70  FF,CF,IG/CF/D,FG
180001V2311  BMH70  FF,CF,IG/CF/D,FG,VV-NC
180001V2400  BMH70  FF,CF,IG/CF/ND
180001V2401  BMH70  FF,CF,IG/CF/ND,VV-NC
180001V2410  BMH70  FF,CF,IG/CF/ND,FG
180001V2411  BMH70  FF,CF,IG/CF/ND,FG,VV-NC
180007V1000  BMH70  EURO,M-BASIC,ISO,NO IG
180007V2000  BMH70  EURO,M-BASIC,Turbo Pump
180008V1010  PT70   F-Compact DN 63 ISO-K
180008V2010  BMH70  EURO,FF,CF,NO IG,FG
