Leybold DIP 3.000 - NEW

Call for Price

In stock
SKU
NEW_DIP3.000
Weight 64 lbs
Pumping Speed 3,000 l/s
Ultimate Pressure < 5 x 10-7 mbar

Leybold DIP 3.000 High Vacuum Diffusion Pump - NEW

The pumps in the DIP series are high-vacuum pumps (<10-2 mbar). They are always operated in conjunction with forevacuum pumps. The DIP series pumps are water cooled and utilize the oil diffusion principle in their operation. They are employed in high-vacuum technology to evacuate vacuum chambers. They achieve their highest pumping speeds in pressure ranges from 10-2 to 10-7 mbar.

The diffusion pumps in the DIP series comprise the following component assemblies:

  • Water-cooled pump housing with high-vacuum, and forevacuum connection flanges
  • Nozzle assembly
  • Vaporization chamber with heating elements
  • Cold cap baffle
  • Forevacuum baffle
  • Energy Efficiency Control or electrical junction box

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Technical Data
DIP 3,000
High-vacuum connection DN 800 ISO-F
Forevacuum connection DN 160 ISO-K
Pumping speed for
hydrogen <10-4 mbar
air1) <1 · 10-4 mbar

l · s-1
l · s-1

3,000
24,500
Working range mbar <10-2 - <10-7
Ultimate total pressure 2) mbar <5 x 10-7
Max. permissible forevacuum pressure mbar 6 x 10-2
Pump fluid fill, min./max. l 10 / 15
Line power supply 5)
Standard, 50/60 Hz
Special, 50/60 Hz

V
V

(± 10 %) 230/400 ~ 3 Ph Δ/Y
460 ~ 3 Ph Δ
Heating power kW 18
Heating cartridges   18
Warm-up period min <30
Coolant (minimum)
for the pump 3)
for the cold cap baffle

l · h-1
l · h-1

900
80
Number of cooling circuits
(including cold cap baffle)

3
Coolant connection
Pump
Cold cap baffle

G
G

1/2"
3/8"
Weight, approx. kg 296
Recom. forevacuum pumps 4)
at working pressures >10-4
at working pressures <10-4

mbar
mbar

SV 300 + W 1001
SV 300 + W 251

Specs

Type Label Description Download
Leybold DIJ & DIP Series - NEW Instruction Manual Download
