Leybold DIVAC 4.8 VT - NEW

Name: Leybold DIVAC 4.8 VT - NEW
Brand: Leybold
SKU: NEW_4.8VT

Be the first to review this product

Call for Price

In stock

SKU

NEW_4.8VT

Request For Quote

Weight	39.7 lbs
Motor Power	0.47 hp
Pumping Speed	4.7 m³/h
Ultimate Pressure	≤ 1.50 x 10⁰ torr

Dimensions

Description

Leybold DIVAC 4.8 VT Dry Diaphragm Vacuum Pump - NEW

The DIVAC T range of diaphragm pumps comprises backing pumps which are used in all applications requiring an especially low base pressure while having to maintain an oil-free vacuum. The DIVAC T pumps have been specially developed as backing pumps for wide range high vacuum turbomolecular pumps.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Specification

Inlet connection	DN 16 ISO-KF, G 3/8" Inside thread
Outlet connection	Silencer, G 3/8" Inside thread
Pumping speed	4.7 m³/h	2.8 cfm
Ultimate pressure	≤ 2.0 mbar / ≤ 1.5 Torr
Max. outlet pressure	2,000 mbar	1,500 Torr
Noise level	55 dB(A)
Mains connection	1-phase, 230 V, ±10%, 50 Hz
Motor rating	350 W	0.47 hp
Rotation speed at 50 Hz	1,500 min^-1	1,500 rpm
Motor protection rating	IP 54
Admissible gas inlet temperature	+5 to +40°C	+41 to +104°F
Admissible ambient temperature	+5 to +40°C	+41 to +104°F
Weight	18 kg	39.7 lbs

Specifications

Digital Manuals

Type	Label	Description	Download
	Leybold Dry Compressing Vacuum Pumps - NEW	Excerpt / Catalog Part	Download

RFQ/Configuration

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Leybold DIVAC 4.8 VT Dry Diaphragm Vacuum Pump - NEW

Part # 12792
