Leybold PHOENIX L300 - REBUILT
Call for Price
In stock
SKU
REBUILT_L300
Leybold PHOENIX L300 Dry Helium Leak Detector - REBUILT
Leybold PHOENIX L300 Dry Helium Leak Detector is a helium leak indicator based on the mass-spectrometric principle of detection. It permits leak tests to be carried out on test objects of virtually all sizes and up to the largest volumes.
Ask about the dry scroll optional.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Smallest detectable He leak rate (Vac mode) | ≤ 2 x 10-11 mbar x l x s-1 |
| Smallest detectable He leak rate (Sniffer mode) | < 1 x 10-7 mbar x l x s-1 |
| Max. detectable He leak rate (Vac mode) | 1 x 10-1 mbar x l x s-1 |
| Max. permissible inlet pressure | 15 mbar / 11.25 Torr |
| Pumping speed during evac. process | |
| 50 Hz | 1.6 m3 x h-1 / 0.94 cfm |
| 60 Hz | 1.9 m3 x h-1 / 1.12 cfm |
| Pumping speed for helium at the inlet | > 2.5 l/s |
| Time constant of the leak signal | < 1 s |
| Leak rate measurment range | 1 x 10-11 to 1 x 10-1 |
| Units of measurment (selectable) | mbar x l x s-1, atm x cc x sec-1, Pa x m3 x s-1, ppm, Torr x l x s-1, g/a, oz/y |
| Time until ready for operation | < 2 min |
| Mass spectrometer | 180 degree magnetic sector field |
| Ion source | 2 yttrium/iridium long life cathodes |
| Detectable masses | 2, 3 and 4 amu |
| Test port | 1 x 25 KF DN |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold PhoeniXL 300 Series - REBUILT | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold PHOENIX L300 Dry Helium Leak Detector - REBUILT
