Leybold PHOENIX Vario - NEW
| Height | 380 mm |
|---|---|
| Width | 313 mm |
| Length | 486 mm |
| Weight | 56 lbs |
Leybold PHOENIX Vario Helium Leak Detector - NEW
Helium leak detector with 180° sector field mass spectrometer. Without integrated backing pump and with two connections for external backing pumps for highest flexibility.
Characteristics
Very compact and portable leak detector with a space saving housing concept. Smallest detectable leak rate of 5 x 10-12 mbarl*l/s, highest measurement accuracy and reliability, very fast run up time and intuitive handling. Offers high flexibiliy with regards to the pumping speed because the type and size of the fore vacuum pump can be freely chosen.
Applications
The all-rounder with variable pumping speed and a small and space saving housing, perfectly suited for systems integration and also for Research & Development, UHV applications, industrial applications or the semiconductor industry.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Specifications | Quadro | Quadro Dry | Magno | Magno Dry | Vario |
|---|---|---|---|---|---|
| Smallest detectable helium leak rate | |||||
| Vacuum operation mbar l/s | ≤ 5 x 10-12 | ||||
| Sniffer mode mbar l/s | < 1 x 10-9 | ||||
| Smallest detectable hydrogen leak rate | |||||
| Vacuum operation mbar l/s | ≤ 1 x 10-8 | ||||
| Sniffer mode mbar l/s | < 1 x 10-7 | ||||
| Units of measurement (selectable) | |||||
| Pressure | mbar, Pa, atm, Torr | ||||
| Leak rate | mbar · l/s, Pa · m3 · s-1, Torr · l/s, atm · cc · sec-1, sft3/yr | ||||
| Sniffer mode | ppm, g/a eq, oz/yr eq | ||||
| Leak rate display area | 1 x 10-12 to 1 x 10-1 | ||||
| Max. inlet pressure | 15 mbar | ||||
| Max. inlet pressure w/ partial flow pump set | 1,000 mbar | ||||
| Pumping speed during evacuation process | |||||
| 50 Hz m3h-1 | 2.5 | 3 | 15 | 5 | Depends on chosen backing pump |
| 60 Hz m3h-1 | 3 | 17 | 6 | ||
| Helium pumping speed in vacuum mode | |||||
| GROSS Modus | 0.4 | 0.04 | < 8 | < 3.5 | - |
| FINE Modus | 1.2 | 1.2 | < 7 | < 2 | - |
| ULTRA Modus | > 3.1 | ||||
| Time constant of the leak signal (blank flanged, 63% of the final value) | < 1 sec | ||||
| Run-up time (after switching on) | ≤ 110 sec | ||||
| Mass spectrometer | 180° magnetic sector field | ||||
| Ion source | 2 yttrium/iridium long-term cathodes | ||||
| Detectable masses | 2, 3 and 4 | ||||
| Inlet flange | 25 ISO-KF | ||||
| Dimensions | 495 x 475 x 319 mm | 521 x 653 x 366 mm | 486 x 380 x 345 mm | ||
| Weight | 40 kg | 35 kg | 67 kg | 56 kg | 30 kg |
| Available languages | English, German, Chinese, Japanese (Katakana), Korean, Russian, French, Italian, Spanish and Polish | ||||
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold PHOENIX Quadro, Magno & Vario Helium Leak Detectors - NEW PHOENIX Quadro 250001V02 Dry 100-240V 250000V02 Wet 230V 251000V02 Wet 115V 251100V02 Wet 100V PHOENIX Magno 350000V02 Wet 200-230V 352200V02 Wet 100-115V 350001V02 Dry 200-230V 352201V02 Dry 100-115V PHOENIX Vario 250002V02 Leak rate: bis 5 x 10-12 mbar l/s
