Leybold RUTA RA 7001 / SV 1200 - NEW
Call for Price
In stock
SKU
NEW_RA7001/SV1200
| Weight | 6615 lbs |
|---|---|
| Motor Power | 45.6 hp |
| Pumping Speed | 5,520 m3/h |
| Ultimate Pressure | < 6 x 10-3 Torr |
Leybold RUTA RA 7001 / SV 1200 / G Roots Vacuum Pump System - NEW
SOGEVAC 2-Stage Frame Version
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| SOGEVAC 2-Stage | Frame Version |
|---|---|
| Inlet connection | DN 250 ISO-K |
| Outlet connection | DN 160 ISO-K |
| Pumping speed at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr | 5,520 m3/h / 3,250 cfm |
| Ultimate partial pressure w/out gas ballast | < 8.0 x 10-3 mbar / < 6.0 x 10-3 Torr |
| Ultimate total pressure w/ gas ballast | < 4.0 x 10-2 mbar / < 3.0 x 10-2 Torr |
| Operating fluid | N 62 |
| Total operating fluid capacity | 62.0 l / 65.5 qt |
| Noise level to DIN 45 635 w/o gas ballast at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr |
82 dB(A) |
| Mains connection | 3-phase, 400 V, 50 Hz |
| Installed motor rating | 33.5 kW / 45.6 hp |
| Power consumption at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr |
18.0 kW / 24.5 hp |
| Admissible ambient temperature | +12 to +40°C / +54 to +104°F |
| Weight | 3,000 kg / 6,615 lbs |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold RUTA RA 7001 / SV 1200 / G Roots Vacuum Pump System - NEW SOGEVAC 2-Stage Frame Version Part no. 02239 / 022 39 Pumping speed: 5,520 m3/h Ultimate pressure: < 4 x 10-2 mbar
