Leybold RUTA W 2001 / E 250 - NEW
| Weight |
2381 lbs |
| Motor Power |
17.7 hp |
| Pumping Speed |
1,350 m3/h |
| Ultimate Pressure |
1.5 x 10-3 Torr |
Leybold RUTA WAU 2001 / E 250 / G Roots Vacuum Pump System - NEW
E / DK 2-Stage Frame Version
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| E / DK 2-Stage |
Frame Version |
| Inlet connection |
DN 100 ISO-K |
| Outlet connection |
DN 63 ISO-K |
| Pumping speed at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr |
1,350 m3/h / 795 cfm |
| Ultimate partial pressure w/out gas ballast |
2.0 x 10-3 mbar / 1.5 x 10-3 Torr |
| Ultimate total pressure w/ gas ballast |
2.0 x 10-2 mbar / 1.5 x 10-2 Torr |
| Operating fluid |
LEYBONOL LVO 100 |
| Total operating fluid capacity |
12.0 l / 12.7 qt |
Noise level to DIN 45 635 w/o gas ballast
maximum
at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr |
83 dB(A)
80 dB(A) |
| Mains connection |
3-phase, 400 V, 50 Hz |
| Installed motor rating |
13.0 kW / 17.7 hp |
Power consumption
at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr |
4.7 kW / 6.4 hp |
| Admissible ambient temperature |
+12 to +40°C / +54 to +104°F |
| Weight |
1,080 kg / 2,381 lbs |
Specs - Frame Version
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold RUTA WAU 2001 / E 250 / G Roots Vacuum Pump System - NEW
E / DK 2-Stage Frame Version
Part no. 02345 / 023 45
Pumping speed: 1,350 m3/h
Ultimate pressure: 2 x 10-2 mbar
Operating fluid: LEYBONOL LVO 100
