Leybold SCROLLVAC 7 plus Dry Scroll Vacuum Pump - NEW
The dry compressing SCROLLVAC pumps operate on the principle of a scroll compressor. Two or more Archimedes spirals engaging each other. The vacuum is generated by reducing the volume of the pockets and compressing gases from the outside towards the inside thereby pumping the gases. SCROLLVAC pumps operate absolutely oil-free with a high effective pumping speed in the whole range of operation.
Features
No oil contamination and higher robustness due to hermetic sealing of rotating parts from pumping chamber
Universal voltage supply (100-127 V, 200-240 V) for constant performance everywhere in the world (single-phase version)
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SCROLLVAC 7 plus Dry Scroll Vacuum Pump - NEW
Part no. 141007V10
Standard version, single-phase motor w/ gas ballast
Mains cables (mandatory, required for operation)
EU - CEE 7/7 (Schuko) - IEC-60320 C19, 2.0 m length
161 810 EU
UK - BS 1363 - IEC-60320 C19, 2.0 m length
161 810 UK
USA (115 V) - NEMA 5-15P - IEC-60320 C19, 2 m length
161 810 US
USA (230 V) - NEMA 6-15P - IEC-60320 C19, 2.5 m length
141 103 US
