Leybold SOGEVAC SV 570 B - NEW
Starting at
$0
In stock
Only %1 left
SKU
NEW_SV570B
| Weight | 1212.5 lbs |
|---|---|
| Motor Power | 18 hp |
| Pumping Speed | 470 m3/h |
| Ultimate Pressure | ≤ 8 x 10-2 mbar |
Leybold SOGEVAC SV 570 B/BF Rotary Vane Vacuum Pump - NEW
The new SOGEVAC range of rotary vane vacuum pumps is setting new standards and offers following major characteristics:
- Pumping speed: 470 m³/h
- Ultimate pressure: 0.08 mbar
- Compact design and small footprint
- Very low and constant noise level in any working condition
- Integrated functions, no external pipe
- No motor coupling up to SV 65 B
- Variant concept / specific customer configurations
- ATEX versions for categories 2 and 3, from SV 40 B to SV 100 B
- Simplified maintenance
All this without any concession to the high technical performance of the SOGEVAC pumps such as ultimate pressure, pump-down time, water vapor tolerance…
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal Speed | ||
| 50 Hz | 470 m3 x h-1 | 277 cfm |
| 60 Hz | 570 m3 x h-1 | 335 cfm |
| Pumping speed | ||
| 50 Hz | 400 m3 x h-1 | 236 cfm |
| 60 Hz | 470 m3 x h-1 | 277 cfm |
| Ultimate total pressure w/o gas ballast | ≤ 8 x 10-2 | |
| Ultimate total pressure w/ gas ballast | ≤ 0.7 mbar | |
| Ultimate total pressure w/ 2 gas ballast valves | ≤ 2.0 mbar | |
| Cooling | air | |
| Motor power | 9.2 kW | |
| Oil filing, min/max | 20/23 l | |
| Noise level | 72 dBA | |
| Oil type | mineral oil LVO 130 | |
| Weight | 550 kg / 1212.5 lbs |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold Oil Sealed - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SOGEVAC SV 570 B/BF Rotary Vane Vacuum Pump - NEW Part no. 960766V Pumping speed: 470 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar Three-phase motor: 230V / 400V, 50/60Hz; 460V, 60Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap Part no. 960765V Pumping speed: 470 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar 3-phase US motor: 230V / 460V, 60Hz; 400V, 50Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap Part no. 760755V Pumping speed: 400 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar Nema-Premium Version 400V ±10%, 50 Hz; 200-230V ±10%, 60Hz; 460V ±10%, 60Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap Operating fluid: LEYBONOL LVO 130 SOGEVAC SV 570 BF Pumping speed: 470 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar 3-phase motor: 230/400V, 50Hz // 460V, 60Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap Part no. 960767V Pumping speed: 470 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar 3-phase US motor: 230V / 460V, 60Hz; 400V, 50Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap Part no. 960759V Pumping speed: 470 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar 400V ±10%, 50 Hz; 200-230V ±10%, 60Hz; 460V ±10%, 60Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap Part no. 11307 (w/o motor) Pumping speed: 4.2 m3/h Ultimate pressure: < 2 x 10-3 mbar w/out motor SOGEVAC SV 570 BF Part no. 960768V Pumping speed: 470 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar 3-ph motor: 230/400V, 50Hz // 460V, 60Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap SOGEVAC SV 570 BF Part no. 960767V Pumping speed: 470 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar 3-ph US motor: 230V / 460V, 60Hz; 400V, 50Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap SOGEVAC SV 570 BF Part no. 960759V Pumping speed: 470 m3/h Ultimate pressure: ≤ 8 x 10-2 mbar 400V ±10%, 50 Hz; 200-230V ±10%, 60Hz; 460V ±10%, 60Hz w/ standard gas ballast 24 V DC,oil filter, thermal switch, oil drain tap Operating fluid: LEYBONOL LVO 130
