Leybold TRIVAC D60A - REBUILT
Weight
210 lbs
Motor Power
2 hp
Pumping Speed
1030 l/m
Ultimate Pressure
3 x 10-4 Torr
Leybold TRIVAC D60A Rotary Vane Vacuum Pump - REBUILT
If the requested voltage is not in stock then we will purchase a new motor and split the cost with you. They run on various vacuum pump oils . PTB Sales' technicians rebuild pumps to OEM specifications led by a Leybold Vacuum factory-trained mechanic. We also offer repair service .
Leybold blower packages are available.
Questions? send an email to our sales team!
Displacement
36.7 cfm
1,030 l/min
Ultimate partial pressure
3 x 10-4 Torr
Ultimate partial pressure w/ gas ballast
5 x 10-3 Torr
Water vapor tolerance
40 Torr
Oil capacity
4 qt
16.8 lbs
Motor power
2 hp
Rotational speed
1,150 rpm
Weight
210 lb
Sound pressure level (max) at 3 feet w/ gas ballast open
60 dB(A)
Sound pressure level (ave) at 3 feet w/ gas ballast open
63 dB(A)
Intake & exhaust connections
KF40
Max. ambient temperature
104°F
Specifications
Type
Label
Description
Download
Leybold-Heraeus TRIVAC A Series - REBUILT
Operating Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TRIVAC D60A Rotary Vane Vacuum Pump - REBUILT
898053 2 HP, T.E.F.C 208V 60 Hz three-phase
898054 2 HP, T.E.F.C 230/460V 60 Hz 3-phase
898251 3 HP, T.E.F.C 220/380V 50 Hz 3-phase
89586
