Leybold TRIVAC D8A - REBUILT
Call for Price
In stock
SKU
REBUILT_D8A
| Weight | 80 lbs |
|---|---|
| Motor Power | 1 hp |
| Pumping Speed | 190 l/m |
| Ultimate Pressure | 3 x 10-4 Torr |
Leybold TRIVAC D8A Rotary Vane Vacuum Pump - REBUILT
If the requested voltage is not in stock then we will purchase a new motor and split the cost with you. They run on various vacuum pump oils. PTB Sales' technicians rebuild pumps to OEM specifications led by a Leybold Vacuum factory-trained mechanic. We also offer repair service.
Leybold blower packages are available.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Displacement | 7.0 cfm | 190 l/min |
| Ultimate partial pressure | 3 x 10-4 Torr | |
| Ultimate partial pressure w/ gas ballast | 3 x 10-3 Torr | |
| Water vapor tolerance | 30 Torr | |
| Oil capacity | 1 qt | 4.2 lbs |
| Motor power | 1 hp | |
| Rotational speed | 1,725 rpm | |
| Weight | 80 lb | |
| Sound pressure level (max) at 3 feet w/ gas ballast open | 60 dB(A) | |
| Sound pressure level (ave) at 3 feet w/ gas ballast open | 57 dB(A) | |
| Intake & exhaust connections | KF25 | |
| Max. ambient temperature | 104°F |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold-Heraeus TRIVAC A Series - REBUILT | Operating Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TRIVAC D8A Rotary Vane Vacuum Pump - REBUILT 898020 898141 720-25-044 720-75-032
