Leybold TURBOVAC 450 i / iX - NEW
Call for Price
In stock
SKU
NEW_TV450i/iX
| Weight | 18 lbs |
|---|---|
| Pumping Speed | 430 l/s |
| Ultimate Pressure | < 8 x 10-8 mbar |
Leybold TURBOVAC 450 i / iX Turbomolecular Vacuum Pump - NEW
The NEW Leybold Vacuum product line TURBOVAC i / iX with integrated drive electronics provides best pumping performance on ISO 100 and 160 flange size. It allows easiest pump integration, operation and control thanks to flexible housing and electronic options and a flexible range of accessories.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| TURBOVAC | 450 i / iX |
|---|---|
| Inlet connection | DN 160 ISO-K / 160 CF |
| Outlet connection | DN 25 KF |
| Pumping speed l/s | |
| N2 | 430 |
| Ar | 400 |
| He | 440 |
| H2 | 420 |
| Gas throughput mbar x l/s | |
| N2 | 4.5 |
| Ar | 2 |
| He | 8 |
| H2 | 8 |
| Compession ratio | |
| N2 | 1 x 1011 |
| Ar | 1 x 1011 |
| He | 1 x 108 |
| H2 | 1 x 106 |
| Ultimate pressure ISO-K/CF w/ 2-stage oil-sealed rotary vane pump |
< 8 x 10-8 mbar (≤ 5 x 10-10 Torr) |
| Max. permissable fore-vacuum pressure for N2 | 10 mbar |
| Operating speed | 60,000 rpm |
| Standard cooling | Convection |
| Optional cooling | Air / Water |
| Weight | 8.2 kg (13 lbs) |
| Recommended fore-vacuum pumps | |
| TRIVAC | D 4 B |
| SCROLLVAC | SC 5 D / SC 15 D |
| DIVAC | 3.8 HV3 |
| Supply voltage | 24/48 VDC ±10% |
| Max. current consumption | 10 A at 24 VDC |
| Max. power consumption | 240 W |
| Interfaces | RS 485, USB, 15-pin digital I/O (additional on request) |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TURBOVAC 450 i / iX Turbomolecular Vacuum Pump - NEW TURBOVAC 450 i RS 485 Part no. 830071V1000 Pumping speed: 430 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 25 ISO-KF TURBOVAC 450 i RS 485 Part no. 830081V1000 Pumping speed: 430 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 160 CF Connecting flange fore-vacuum: DN 25 ISO-KF TURBOVAC 450 i PB Part no. 830071V2400 Pumping speed: 430 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 25 ISO-KF TURBOVAC 450 iX Part no. 830071V3300 Pumping speed: 430 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 25 ISO-KF TURBOVAC 450 iX Part no. 830081V3300 Pumping speed: 430 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 160 CF Connecting flange fore-vacuum: DN 25 ISO-KF TURBOVAC 450 iX Part no. 830071V3000 Pumping speed: 430 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 25 ISO-KF TURBOVAC 450 iX Part no. 830081V3000 Pumping speed: 430 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 160 CF Connecting flange fore-vacuum: DN 25 ISO-KF
