Leybold TURBOVAC 90 i / iX - NEW
Call for Price
In stock
SKU
NEW_TV90i/iX
| Weight | 7.90 lbs |
|---|---|
| Pumping Speed | 90 l/s |
| Ultimate Pressure | < 8 x 10-8 mbar |
Leybold TURBOVAC 90 i / iX Turbomolecular Vacuum Pump - NEW
The NEW Leybold Vacuum product line TURBOVAC i / iX with integrated drive electronics provides best pumping performance on ISO 100 and 160 flange size. It allows easiest pump integration, operation and control thanks to flexible housing and electronic options and a flexible range of accessories.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| TURBOVAC 90 i / iX | 810031V1000 | 810031V3300 | 810041V1000 | 810041V3300 |
|---|---|---|---|---|
| Inlet connection | DN 63 ISO-K | DN 63 CF | ||
| Outlet connection | DN 16 ISO-KF | |||
| Pumping speed | ||||
| N2 | 90 l/s | |||
| Ar | 83 l/s | |||
| He | 90 l/s | |||
| H2 | 78 l/s | |||
| Gas throughput | ||||
| N2 | 10 mbar x l/s | |||
| Ar | 3 mbar x l/s | |||
| He | 11 mbar x l/s | |||
| H2 | ||||
| Compression ratio | ||||
| N2 | 1.0 x 1011 | |||
| Ar | ||||
| He | - | |||
| H2 | 5.0 x 107 | |||
| Ultimate pressure | < 8.0 x 10-8 mbar / < 6 x 10-8 Torr | < 5.0 x 10-10 mbar / ≤ 3.8 x 10-10 Torr | ||
| Max. foreline pressure for N2 | 14.0 mbar / 10.5 Torr | |||
| Nominal rotation speed | 72,000 min-1 / 72,000 rpm | |||
| Rotational speed adaptation | 62 - 100% | |||
| Run-up time | ≈ 1.5 min | |||
| Admissible ambient temperature | +5 to +45°C / +41 to +113°F | |||
| Standard cooling | Convection | |||
| Optional cooling | Air / Water | |||
| Cooling water connection | Plug connection for 6x1 hose Alternative G 1/8" screw in thread |
|||
| Cooling water consumption | 30 - 60 l/h | |||
| Permissible cooling water pressure | 3 - 6 bar | |||
| Permissible cooling water temperature | +15 to +35°C / +59 to +95°F | |||
| Noise level | ≤ 41 db(A) | |||
| Weight | 3.1 kg / 6.8 lbs | 3.6 kg / 7.9 lbs | 5.3 kg / 4.8 lbs | 3.1 kg / 4.8 lbs |
| Integrated vacuum system controller | No | Yes | No | Yes |
| Mains connection | 24/48 VDC ±10% | |||
| Max. current consumption | 10 A at 24 VDC | |||
| Max. power consumption | 240 W | |||
| Power consumption at ultimate pressure (24V/48V) | 7 W / 9.5 W | |||
| Interfaces | USB+, 15-pin digital I/O, RS485 | |||
| Protection class | IP 40 | |||
| Recommended fore-vacuum pumps | TRIVAC D 2,5 E / D 4 B SCROLLVAC SC 5 D , DIVAC 1.4 HV3 |
|||
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TURBOVAC 90 i / iX Turbomolecular Vacuum Pump - NEW TURBOVAC 90 i Part no. 810031V1000 Pumping speed: 90 l/s (Nitrogen) Ultimate pressure: < 10-8 mbar Connecting flange high-vacuum: DN 63 ISO-K Connecting flange fore-vacuum: DN 16 ISO-KF TURBOVAC 90 i Part no. 810041V1000 Pumping speed: 90 l/s (Nitrogen) Ultimate pressure: < 10-10 mbar Connecting flange high-vacuum: DN 63 CF Connecting flange fore-vacuum: DN 16 ISO-KF TURBOVAC 90 iX Part no. 810031V3300 Pumping speed: 90 l/s (Nitrogen) Ultimate pressure: < 10-8 mbar Connecting flange high-vacuum: DN 63 ISO-K Connecting flange fore-vacuum: DN 16 ISO-KF TURBOVAC 90 iX Part no. 810041V3300 Pumping speed: 90 l/s (Nitrogen) Ultimate pressure: < 10-10 mbar Connecting flange high-vacuum: DN 63 CF Connecting flange fore-vacuum: DN 16 ISO-KF
