Leybold TURBOVAC MAG W 1600 iP - REBUILT
Call for Price
In stock
SKU
REBUILT_MAGW1600IP
| Weight | 150 lbs |
|---|---|
| Pumping Speed | 1,600 l/s |
| Ultimate Pressure | 1 x 10-8 mbar |
Leybold Vacuum TURBOVAC MAG W 1600 iP Turbomolecular Pump - REBUILT
Accuracy, precision and reliability those are the features of these magnetically-levitated turbomolecular pumps. High pumping speed and gas throughput for faster pump down time improve equipment cycle times. With its fully integrated converter and power supply, conventional rack-mounted controller and interconnecting cables are no longer necessary.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet flange | DN 250 ISO-F |
| Pumping speed | |
| N2 | 1,600 l/s |
| Ar | 1,470 l/s |
| He | 1,770 l/s |
| H2 | 1,570 l/s |
| Max compression | |
| N2 | > 107 |
| Ar | > 107 |
| He | 6 x 104 |
| H2 | 1 x 103 |
| Max gas throughput | |
| N2 temporary, for pump down | 60 mbar x l/s |
| N2 continuous operation | 30 mbar x l/s |
| Ar temporary, for pump down | 30 mbar x l/s |
| Ar continuous | 20 mbar x l/s |
| Max. forevacuum pressure | 4 mbar |
| Nominal speed | 37,800 min-1 |
| Stand-by speed to be set between and nominal speed | 13,800 min-1 (230 Hz) |
| Ultimate pressure ISO-F / CF flange | < 10-8 mbar / < 10-10 mbar |
| Max. bake-out temperature | 80°C |
| Run-up time | < 7 min |
| Forevacuum flange | DN 40 KF |
| Purge gas / venting flange | DN 16 KF (clamp shoe) |
| Weight, approx. | 45 kg |
| Noise level acc. to ISO 3744 | < 41 db(A) |
| Vibration level at high-vacuum flange at max. speed | < 0.01 μm |
Specifications
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold TURBOVAC MAG Integra Series - REBUILT | Operating Instructions | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC MAG W 1600 iP Turbomolecular Pump - REBUILT 411600V0504 MAG W 1600 iP Booster, DN 250 ISO-F, Profibus 411600V0514 MAG W 1600 iP Booster, DN 250 ISO-F, 24 V SPS interface 411600V0544 MAG W 1600 iP Booster, DN 250 ISO-F 411600V0704 MAG W 1600 iPL Booster, DN 250 ISO-F, Profibus 411600V0714 MAG W 1600 iPL Booster, DN 250 ISO-F, 24 V SPS interface
