Leybold TURBOVAC MAG W 2200 / C / CT - REBUILT
Call for Price
In stock
SKU
REBUILT_MAGW2200CT
| Weight | 105.80 lbs |
|---|---|
| Pumping Speed | 2000 l/s |
| Ultimate Pressure | 1 x 10-8 mbar |
Leybold Vacuum TURBOVAC MAG W 2200 / C / CT Turbomolecular Vacuum Pump - REBUILT
Accuracy, precision and reliability those are the features of these magnetically-levitated turbomolecular pumps. High pumping speed and gas throughput for faster pump down time improve equipment cycle times. With its fully integrated converter and power supply, conventional rack-mounted controller and interconnecting cables are no longer necessary.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet connection | DN 250 CF |
| Outlet connection | DN 40 ISO KF |
| Ultimate pressure | < 1.0 x 10-10 mbar |
| Max. foreline pressure for N2 | 1.0 mbar |
| Nominal rotation speed | 29,400 min-1 |
| Run up time | ≈ 8 min |
| Max. power consumption | 1,100 W |
| Power consumption at ultimate pressure | 100 W |
| Protection rating | IP 20 |
| Admissible ambient temperature | 5 - 40°C |
| Cooling standard | Water |
| Cooling water connection | 1/4" tube |
| Cooling water consumption | 120 - 350 l/h |
| Permissible cooling water pressure | 2 - 7 bar |
| Permissible cooling water temperature | 10 - 30°C |
| Weight | 132 lbs |
Specifications
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold MAG digital Series - REBUILT | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC MAG W 2200 / C / CT Turbomolecular Pump - REBUILT 400081V0010 MAG W 2200 C DN 200 ISO-F 400081V0011 MAG W 2200 C DN 200 ISO-F 400081V0020 MAG W 2200 C DN 250 ISO-F-N2 400081V0021 MAG W 2200 C DN 250 ISO-F 400081V0022 MAG W 2200 CT Drive IM 400081V0023 MAG W 2200 CT DN 250 ISO-F
