VIC MS-50GT - NEW
Call for Price
VIC Vacuum Instruments Corporation, LLC MS-50GT Automated High-Speed Production Helium Leak Detector - NEW
Because it offers a choice of three flow modes, the MS-50GT adapts to many leak testing applications. Reverse flow offers the fastest time to test for large to fine leaks. Direct flow provides the fastest response time for the smallest of leaks. A combination mode that enables the system to switch automatically between modes provides optimum performance.
This unique flexibility of flow modes allows the MS-50GT to test for leaks in many applications for industries that require any level of leak tightness. The MS-50GT can be used for applications In a broad range of industries such as the aerospace, automotive, chemical, cosmetics, electronics, food processing, medical, packaging, pharmaceutical, refrigeration, semiconductor, utilities, and vacuum industries.
- Dual Pump System (dedicated foreline and roughing pumps) completely eliminates tracer gas contamination during the roughing cycle.
- NIST Traceable Temperature Compensated Internal Calibrator provides maximum calibration accuracy.
- Dual Filament Source provides a spare filament allowing continued testing until scheduled maintenance.
- Test for the Smallest Leaks at the Highest Inlet Pressures the mass spectrometer design enables the MS-50GT to test for the smallest leaks at the highest pressure. Gross testing begins at 100 Torr. Fine leak testing begins at 7.5 Torr.
- Detectable Tracer Gas Masses include Helium, Argon, Hydrogen and Helium-3.
- Depending upon your applications, models range from Wet, Dry, High Sensitivity and Dual Port.
The MS-50GT is the only production leak detector with an interactive touch screen display and built-in diagnostics for trouble-free maintenance. Simple one-button power up has system ready to test in less than 3 minutes. Automatic start-up, tuning and calibration along with three flow modes provide flexibility and maximum productivity for applications specific leak testing.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Specifications | MS-50GT | MS-50GT Dry | MS-50GT Dry HS |
|---|---|---|---|
| Sensitivity, vacuum | 3.0 x 10-11 | 3.0 x 10-12 | |
| Sensitivity, sniffing | 1.0 x 10-08 | ||
| Leak measurement range | 3.0 x 10-11 to 10 | 3.0 x 10-12 to 1.0 x 10-5 | |
| Leak ranging | Auto / Manual | ||
| Start-up time | < 3 min. | ||
| Response time | < 2 sec. direct, < 2.5 sec. reverse | < 2 sec. | |
| Resolution | 14 at mass 4 | ||
| Gross Test, Time (w/ UFT Option) | 3 sec. (100 mTorr) | ||
| Fine Test, Time (w/ UFT Option) | 10 sec. (25 mTorr, 10-10 atm-cc/sec) | ||
| Mass spectrometer tube | 180° deflection; dual-magnetic sector | ||
| Auto-tuning | Yes | ||
| Auto-calibration | Internal: Yes / External: Manual | ||
| Auto-zeroing | Yes | ||
| Reject set-point | Yes | ||
| Built-in calibrated leak | Yes; 10-08 range | Yes; 10-09 range | |
| NIST traceable | Yes | ||
| Temperature compensated | Yes | ||
| Scan / Descan | Yes | ||
| Filaments | 2 - Tungsten | ||
| Maximum operating pressure | 7.5 Torr direct, 760 Torr reverse | ||
| Display / Interface | 10 in. (25.4 cm) LCD flat panel display, capacitive touch-screen / Graphical User Interface (GUI) | ||
| Units | cc/second, mbar*l/second, Pa*M3 /second | ||
| I/O | 0~5V chart, parallel printer | ||
| Printer Port | Yes | ||
| RS-232C | Yes | ||
| Software | 50 programmable test recipes | ||
| Vacuum mode | Direct, reverse or combination | Direct | |
| Roughing pump | 16 cfm direct drive | 10 cfm dry scroll pump | |
| Foreline pump | 7 cfm direct drive | 5 cfm dual stage diaphragm/molecular drag | |
| High vacuum pump | 61 liters/second turbo pump | ||
| Vacuum gauging | Pirani: Test port & foreline / Ion: High vacuum | ||
| Cold Trap | N/A | Optional | |
| Dimensions (W x H x D) | 25.75 x 30.625 x 35.25 in. (65.40 x 77.79 x 89.54 cm) | ||
| Test Cup, UFT Option (Ø x D) | 4.5 x 1.0 in. (11.4 x 2.5 cm) | ||
| Test port connection | 1.125 in. | ||
| Weight | 475 lbs. (215.45 kg) | ||
| Power | 115 V / 50-60 Hz / 30 A; 230-240 V / 50-60 Hz / 15 A; 100 V / 50-60 Hz / 30 A | ||
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
VIC Vacuum Instruments Corporation, LLC MS-50GT Automated High-Speed Production Helium Leak Detector - NEW
013991000 / 0139-910-00 MS-50GT Automated High-Speed Production Console Helium Leak Detector
013991100 / 0139-911-00 MS-50GT DUAL PORT Automated High-Speed Production Console Helium Leak Detector
013991400 / 0139-914-00 MS-50GT DRY High Sensitivity Automated High-Speed Production Console Helium Leak Detector
013991220 / 0139-912-20 MS-50GT ARGON DRY Automated High-Speed Production Console Argon Leak Detector
013901901 / 0139-019-01 MS-50GT Backfill Station for MS-50 GT models
MS-50FT UFT Ultra Fast Test Production Console Helium Leak Detector
