Adixen Alcatel ADP 122 L - REBUILT
| Weight |
540 lbs |
| Pumping Speed |
55.8 cfm |
| Ultimate Pressure |
9 x 10-2 mbar |
|---|
Adixen Alcatel ADP 122 L Semiconductor Dry Vacuum Pump - REBUILT
The pump is designed for applications that require the pumping of clean (dust-free) and non-corrosive gases. Examples are:
- Instrumentation
- Gas analysis
- Electronic microscope
- X-ray spectrometer
- Leak detection
- Surface analyzer
- Research and development
- Semiconductor fabrication
- Load lock and transfer chamber pumping
- Wafer back pumping
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| 60 Hz |
| Peak pumping speed |
112 m3/h |
65.8 cfm |
1,867 l/mn |
| Typical ultimate pressure |
9 x 103 mbar |
6.7 x 103 Torr |
| Max. ultimate pressure |
1.5 x 10-2 mbar |
1.1 x 10-2 Torr |
| Ultimate pressure |
5 x 10-2 mbar |
3.7 x 10-2 Torr |
| Power at ultimate |
1.5 kW |
| Motor rating |
1.5 kW |
| 50 Hz |
| Peak pumping speed |
95 m3/h |
55.8 cfm |
1,583 l/mn |
| Typical ultimate pressure |
1 x 10-2 mbar |
7.5 x 10-2 Torr |
| Max. ultimate pressure |
3 x 10-2 mbar |
2.2 x 10-2 Torr |
| Ultimate pressure |
9 x 10-2 mbar |
6.7 x 10-2 Torr |
| Power at ultimate |
1.3 kW |
| Motor rating |
1.5 kW |
| Type |
Label |
Description |
Download |
|
|
Adixen Pfeiffer ADP / ADS Series Two - REBUILT |
Operating Instructions |
Download
|
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Adixen Alcatel ADP 122 L Semiconductor Dry Vacuum Pump - REBUILT
