AERZEN GMB 16.13 HV - REBUILT
Call for Price
In stock
SKU
REBUILT_GMA16.13HV
| Weight | 3,300 lbs |
|---|---|
| Motor Power | 30 hp |
| Pumping Speed | 9,750 m3/h |
AERZEN GMB 16.13 HV Roots Vacuum Blower - REBUILT
The blowers made by Aerzener series HV have been designed for conveying air and neutral gases and are especially used in industrial High Vacuum technology. With a total of 19 sizes the blowers cover theoretical nominal intake volume flows from 180 to 97,000 m3/h and pressure ranges from 10-3 mbar abs. up to approx. 200 mbar abs.
Examples for the various fields of application:
- Coating technology chemistry
- Process technology metallurgy / construction of melting furnaces
- Packing industry central vacuum plants
- Helium leakage detection units
- Manufacture of lamps and tubes
- Drying technology
- Machine construction
- Electronics
- Automobile industry
Features:
- Three lobe rotors.
- Cylinder with pre inlet channels to cancel internal pulsations.
- Helical cut timing gears, hydraulically expanded onto their shafts for accurate timing of the rotors.
- Piston ring labyrinth seals with neutral chambers for oil free conveying.
- Cast iron end covers to provide strength and prevent oil leaks.
- Splash fed oil lubrication at the drive and non drive end to give long bearing and timing gears life.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Direct Drive / 4TG-3381 | GMB 16.12 HV | GMB 16.f13 HV | GMB 16.13 HV | GMB 17.15 HV |
|---|---|---|---|---|
| Normal speed 50 Hz / 60 Hz | ||||
| Differential pressure P max. | 265 mbar | 180 mbar | 160 mbar | 133 mbar |
| Speed n max. | 1,500 rpm | 1,000 rpm | ||
| Motor P max. | 45 kW | |||
| Theor. intake volume flow Sth | 5,400 m3/h | 8,150 m3/h | 9,750 m3/h | 10,700 m3/h |
| Higher speed w/ oil feed device | ||||
| Differential pressure P max. | 100 mbar | |||
| Speed n max. | 1,800 rpm | 1,200 / 1,500 rpm | ||
| Motor P max. | 45 kW | 75 kW | ||
| Theor. intake volume flow Sth | 6,500 m3/h | 9,800 m3/h | 11,700 m3/h | 13,000 / 16,000 m3/h |
| V-Belt Drive / 4TG-3382 | GMB 16.12 HV | GMB 16.f13 HV | GMB 16.13 HV | GMB 17.15 HV |
|---|---|---|---|---|
| Normal speed 50 Hz / 60 Hz | ||||
| Differential pressure P max. | 120 mbar | 80 mbar | 65 mbar | |
| Speed n max. | 1,500 rpm | 1,000 rpm | ||
| Motor P max. | 22 kW | 30 kW | ||
| Blower pulley d min. | 400 mm | 560 mm | ||
| Theor. intake volume flow Sth | 5,400 m3/h | 8,150 m3/h | 9,750 m3/h | 10,700 m3/h |
| Higher speed w/ oil feed device | ||||
| Differential pressure P max. | 100 / 80 mbar | 100 / 60 mbar | 65 / 53 mbar | 65 mbar |
| Speed n max. | 2,000 / 2,350 rpm | 1,500 rpm | ||
| Motor P max. | 30 kW | 37 kW | ||
| Blower pulley d min. | 315 / 280 mm | 450 mm | ||
| Theor. intake volume flow Sth | 7,250 / 8,500 m3/h | 10,800 / 12,800 m3/h | 13,000 / 15,250 m3/h | 16,000 m3/h |
Specifications
| Type | Label | Description | Download |
|---|---|---|---|
|
AERZEN GMA & GMB - REBUILT | Operating Instructions | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
AERZEN GMB 16.13 HV Roots Vacuum Blower - REBUILT GMB 16.12 : 3,839 cfm GMB 16.F13 : 5,765 cfm GMB 16.13 : 6,871 cfm Leybold RA-9001
