Agilent Varian HS 652 - REBUILT
Call for Price
| Weight | 73 lbs |
|---|---|
| Pumping Speed | 23.8 cfm |
| Ultimate Pressure | 2 x 10-3 mbar |
Agilent Varian HS 652 Smart Rotary Vane Vacuum Pump - REBUILT
The first rotary vane pumps with truly “smart” capabilities.
Agilent’s HS 452 and HS 652 pumps employ an innovative frequency inverter technology that delivers optimal and consistent performance while encompassing the worldwide range of voltage and frequency conditions.
Operating with low power requirements, the microprocessor controlled frequency inverter, combined with a 3-phase motor, is an efficient driving unit capable of delivering the high starting torque required of a dual- stage oil pump.
HS 452 and HS 652 technology solves the common problems inherent in traditional single-phase motors. Smart Pumps start with inrush current about 7 times lower than that of equivalent traditional pumps.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Free air displacement | 658 l/min (39.5 m3/h) |
| Pumping speed | 29.5 m3/h |
| Ultimate partial pressure | 10-4 mbar |
| Ultimate total pressure | 2 x 10-3 mbar |
| Ultimate total pressure w/ gas ballast | 1 x 10-2 mbar |
| Water vapor tolerance | 30 mbar |
| Water vapor capacity | 550 g/h |
| Oil capacity | 0.6 liter min / 1 liter max |
| Motor rating | 0.5 kW 3-phase |
| Nominal rotation speed | 1,980 rpm |
| Noise level w/ gas ballast closed | ≤ 60 dB(A) |
| Oil temperature | 75°C / 169°F |
| Installation category | II |
| Pollution degree | 2 |
| Operating temperature range | 12-40°C |
| Weight | 33 kg (73 lbs) |
| Inlet/Exhaust flange | 25 KF DN |
| Operating voltage | 100-120 V / 200-240 V |
| Maximum input power | 1,000 VA |
| Main fuse (T type) | 10 A |
Specifications
| Type | Label | Description | Download |
|---|---|---|---|
|
Varian HS Series - REBUILT | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Agilent Varian HS 652 Smart Rotary Vane Vacuum Pump - REBUILT 9499365 / 949-9365 HS 652 Smart Pump single-phase worldwide motor
