Agilent TwisTorr 404 FS - NEW
| Weight | 52.3 lbs |
|---|---|
| Pumping Speed | 380 l/s |
| Ultimate Pressure | 1 x 10-10 mbar |
Agilent TwisTorr 404 FS Turbomolecular Vacuum Pump - NEW
The Agilent 400 l/s medium turbo pump, TwisTorr 404 FS, combines TwisTorr drag stage technology and Agilent Floating Suspension (FS) to provide high performance, reliability, and economy. This 400 liter turbomolecular pump delivers high vacuum performance thanks to the synergy between turbo technology and innovative TwisTorr drag stages. Floating Suspension assures low vibration and acoustical noise for compatibility with sensitive instrumentation and work environments.
The TwisTorr 404 FS is perfectly suited for a wide range of applications, including research and development, UHV systems, nuclear research, ion implanters, surface analysis, electron microscopy, and cryogenics.
The TwisTorr 404 FS is available with onboard or rack controllers.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Pumping speed | ISO-100K / ISO-100F / 6" CF | |
| N2 | 380 l/s | |
| He | 505 l/s | |
| H2 | 415 l/s | |
| Ar | 340 l/s | |
| Max gas throughput | Air cooling (25°C ambient temp) | Water cooling (15°C water temp / 25°C ambient temp) |
| N2 | 4.3 mbar l/s (255 sccm) | 6.2 mbar l/s (367 sccm) |
| He | 7.9 mbar l/s (467 sccm) | 10.4 mbar l/s (615 sccm) |
| Ar | 1.5 mbar l/s (89 sccm) | 3.3 mbar l/s (195 sccm) |
| Compression ratio & foreline tolerance | ||
| N2 | > 1 x 1011 | 10 mbar |
| He | 2 x 108 | 10 mbar |
| H2 | 3 x 106 | > 4 mbar |
| Ar | > 1 x 1011 | 8.5 mbar |
| Base pressure with recommended forepump | < 1 x 10-10 mbar (< 1 x 10-10 Torr) | |
| Inlet flange | ISO-100K / ISO-100F / 6" CF | |
| Foreline flange | NW25 (NW16 as optional accessory) | |
| Rotational speed | Auto setting from 40,800 rpm to 49,500 rpm | |
| Start up time | < 5 minutes | |
| Recommended forepump | DS 302, IDP-10, IDP-15 | |
| Operating position | Any | |
| Operating ambient temperature | +5°C to +35°C | |
| Relative humidity of air | 0 - 90 % (not condensing) | |
| Bakeout temperature | ISO: 80°C at inlet flange CFF: 120°C at inlet flange |
|
| Lubricant | Permanent lubrication | |
| Cooling requirements | ||
| Air cooling | Air temp from +5°C to +35°C | |
| Water cooling | Water temp from +15°C to +25°C Water flow min. 100 l/h |
|
| Noise pressure level | < 50 dB(A) at 1 meter | |
| Storage temperature | -40°C to +70°C | |
| Max altitude | 3,000 m | |
| Weight | ISO-100K 49.8 lbs ISO-100F 52.3 lbs 6" CF 51.8 lbs |
| Type | Label | Description | Download |
|---|---|---|---|
|
Agilent TwisTorr 404 FS - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Agilent TwisTorr 404 FS Turbomolecular Vacuum Pump - NEW X351164004 / X3511-64004 ISO-100K air cooling X351164005 / X3511-64005 ISO-100F air cooling X351164019 / X3511-64019 ISO-100K water cooling X351164020 / X3511-64020 ISO-100F water cooling X351164006 / X3511-64006 6" CF air cooling X351164021 / X3511-64021 6" CF water cooling
