Agilent TwisTorr 704 FS - NEW
| Weight | 49.7 lbs |
|---|---|
| Pumping Speed | 660 l/s |
| Ultimate Pressure | < 1 x 10-10 mbar |
Agilent TwisTorr 704 FS Turbomolecular Vacuum Pump - NEW
The Agilent TwisTorr 704 FS turbomolecular high-vacuum pump combines TwisTorr drag stage technology and Agilent Floating Suspension to provide high performance, reliability, and economy.
TwisTorr drag stages create high compression ratios for light gases such as hydrogen and helium to deliver high throughput and high tolerance of foreline pressure, thereby permitting the use of smaller and more economical backing pumps. This technology results in a compact rotor design that is energy-efficient and maintains a low operating temperature.
The Agilent Floating Suspension system reduces noise and vibration, and ensures optimal bearing operating conditions to extend operating life, minimize system downtime, and assure stability over time.
The unique bearing and dry lubrication in the TwisTorr 704 FS eliminate oil and maintenance, and permit operation of the pump in any orientation. Available with onboard or rack controllers.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| TwisTorr 704 FS | ISO-160 | 8" CF |
|---|---|---|
| Pumping speed | ||
| N2 | 660 l/s | |
| He | 640 l/s | |
| H2 | 480 l/s | |
| Ar | 625 l/s | |
| Gas throughput at full speed | Ambient temp. (25°C) | Water temperature. (25°C, 50 l/h) |
| He | 7.9 mbar l/s | 10.4 mbar l/s |
| N2 | 4.3 mbar l/s | 6.2 mbar l/s |
| Ar | 1.5 mbar l/s | 3.3 mbar l/s |
| Compression ratio and foreline tolerance | ||
| N2 | > 1E + 11 | 10 mbar |
| He | 2E + 08 | 10 mbar |
| H2 | 3E + 06 | > 4 mbar |
| Ar | > 1E + 11 | 8.5 mbar |
| Base pressure with recomm. forepump | < 1 x 10-10 mbar | |
| Inlet flange | ISO-160K, ISO-160F, 8” CF | |
| Foreline flange | NW25 | |
| Rotational speed | Auto setting from 40,800 rpm to 49,500 rpm | |
| Start-up time | < 5 minutes |
| Type | Label | Description | Download |
|---|---|---|---|
|
Agilent TwisTorr 704 FS - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs. Please follow the above link, and fill out the quote form.
Agilent TwisTorr 704 FS Turbomolecular Vacuum Pump - NEW X351164000 / X3511-64000 ISO-160K KF-25 air cooling X351164001 / X3511-64001 ISO-160F KF-25 air cooling X351164002 / X3511-64002 8" CF KF-25 air cooling X351164003 / X3511-64003 8" CF Long-Neck KF-25 air cooling X351164015 / X3511-64015 ISO-160K KF-25 water cooling X351164016 / X3511-64016 ISO-160F KF-25 water cooling X351164017 / X3511-64017 8" CF KF-25 water cooling X351164018 / X3511-64018 8" CF Long-Neck KF-25 water cooling
